Steering – Simplicity REGENT 500 User Manual
Page 7
The above parts group applies to the following Mfg. Nos.:
1693074
Regent 14G
1693076
Regent 14G
1693080
Regent 14H
1693082
Regent 14H
1693084
Regent 16G
1693086
Regent 16G
1693088
Regent 16H
1693090
Regent 16H
1693092
514G, 14G
1693094
514H, 14H
1693098
516H, 16H
1693100
2514G, 14G
1693102
2514H, 14H
1693104
2516H, 16H
1693323
Regent 14G
1693325
Regent 14H
1693329
Regent 16H
1693331
Regent 14G
1693333
Regent 14H
1693337
Regent 16H
1693339
514G, 14G
1693341
514H, 14H
1693343
516H, 16H
1693345
2514G, 14G
1693347
2514H, 14H
1693349
2516H, 16H
5
TP-400-2146-01-RG-SMA
REF NO.
PART NO.
QTY.
DESCRIPTION
Footnotes:
Steering
1
1713841
1
STEERING WHEEL ASSEMBLY, (Incl. CAP Ref. 2)
2
1714097
1
CAP, Steering Wheel
3
1714400
1
TUBE, Flex
4
1960540
1
PIN, Spring, 5/16 x 2-1/2
5
1718539
1
SHAFT ASSEMBLY, Steering
6
1931350
2
CARRIAGE BOLT, 3/8-16 x 1
7
1960114
4
WASHER, 3/4
8
1928352
2
NUT, Hex Flange Whiz Lock, 3/8-16
9
1920415
1
CAPSCREW, Hex Hd, 3/8-16 x 1-1/4
10
1922611
1
WASHER, 3/8
11
1713375
1
STEERING GEAR ASSEMBLY
12
1713469
1
DRAG LINK
13
1930645
3
NUT, Hex Flange Whiz Lock, 3/8-16
14
1611710
3
KLIPRING
15
1713453
1
ARM, Steering, LH
16
1960160
2
WASHER, 3/4
17
1713570
2
SPINDLE ASSEMBLY
18
1713791
2
SPACER
19
1919314
1
PIN, Cotter, 3/16 x 1-1/4
20
1713454
1
TIE ROD
21
1713452
1
ARM, Steering, RH
22
1960268
2
CARRIAGE BOLT, 3/8-16 x 1-1/4
23
1931335
1
CARRIAGE BOLT, 5/16-18 x 1
24
1710437
1
SPACER
25
1935048
1
NUT, Hex Flange Lock, 5/16-18
26
1664847
2
CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 3/4
27
1666001
1
BUSHING
28
176440
1
BUSHING
29
1703508
1
PLATE, Steering, Mounting
