Electrical group - hydro models – Simplicity REGENT 500 User Manual
Page 29
Electrical Group - Hydro Models
27
TP-400-2146-01-RG-SMA
REF NO.
PART NO.
QTY.
DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693080
Regent 14HP Hydro
1693082
Regent 14HP Hydro (Ex)
1693088
Regent 16HP Hydro
1693090
Regent 16HP Hydro (Ex)
1693094
514H, 14HP Hydro
1693098
516H, 16HP Hydro
1693102
2514H, 14HP Hydro
1693104
2516H, 16HP Hydro
1693325
Regent 14HP Hydro
1693329
Regent 16HP Hydro
1693333
Regent 14HP Hydro (Ex)
1693337
Regent 16HP Hydro (Ex)
1693341
514H, 14HP Hydro
1693343
516H, 16HP Hydro
1693347
2514H, 14HP Hydro
1693349
2516H, 16HP Hydro
1
1931333
1
CARRIAGE BOLT, 5/16-18 x 3/4
2
1713756
1
CLAMP, Battery
3
1919326
1
WASHER, Plain, 5/16
4
1919438
1
NUT, Hex Nylon Lock, 5/16-18
5
1704581
1
CAP, Vent, Battery
6
1685215
1
BATTERY
7
1704583
1
HOSE, Drain
8
1704379
1
SWITCH, Pedal, N.O., Black
9
1714770
1
SWITCH, Pedal, N.C., Gray
10
932747
3
TIE
11
1715010
1
WIRE ASSEMBLY, Seat Switch
12
1715014
1
TUBE, Shrink
13
1717457
1
WIRING HARNESS, Main
14
1703799
1
SWITCH, Headlights
15
1716332
1
SWITCH, PTO
16
1703484
2
CABLE, (Solenoid to Starter & Battery to Ground)
17
122023
1
COVER, Terminal
18
1677296
1
BOOT, Insulator
19
1917356
2
LOCKWASHER, 5/16
20
1920263
2
NUT, Hex, 5/16-24 NF
21
1603618
1
CABLE, Battery, Positive
22
1921319
2
WASHER, 1/4
23
1923341
2
CAPSCREW, Hex Hd., 1/4-20 x 3/4
24
1916964
2
LOCKWASHER, 1/4
25
1916622
2
NUT, Hex, 1/4-20, UNC
26
934683
1
CLIP, Wire
27
1685290
1
SOLENOID
28
1927429
1
CAPSCREW, Taptite Hex Washer Hd, 1/4-20 x 5/8
29
1665238
1
CIRCUIT BREAKER
30
1665237
1
WIRE ASSEMBLY
31
1716061
1
SWITCH, Ignition, 6-Pole
32
1960547
1
WASHER, Lock, Internal Tooth, 5/8
33
101025
1
WASHER, 5/8
34
1717549
1
NUT, Hex, Flange, 5/8-32
35
1717550
1
COVER, Ignition
36
1717163
2
KEY, Ignition
