44” Mower Deck - Belt, Idler Arm & Hitch
51 TP-400-2146-01-RG-SMA
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693169 44” Mower Deck
1693188 44” Mower Deck
1693189 44” Mower Deck
1 1718017 1 V-BELT
2 1921972 1 CAPSCREW, Hex Hd, 3/8-16 x 2-1/2
3 1924940 3 WASHER, 3/8
4 171247 1 PULLEY ASSEMBLY
5 1667812 1 SPACER
6 1665835 1 GRIP, Lever
7 1718020 1 ARM, Idler
8 1916965 1 LOCKWASHER, Spring, 3/8
9 1916950 1 NUT, Hex, 3/8-16
10 1930645 1 NUT, Hex Flange Whiz Lock, 3/8-16
11 1715772 1 SPRING
12 1960339 1 NUT, Hex, Center Lock, 3/8-16
13 1924356 2 WASHER, 3/8
14 1714255 1 SPACER, Idler Arm
15 1922605 1 CAPSCREW, Hex Hd, 3/8-16 x 1-1/4”
16 1921969 2 CAPSCREW, Hex Hd, 3/8-16 x 1-1/2
17 157081 2 SPACER
18 1919384 1 WASHER, 3/8
19 1919439 2 NUT, Hex Nylon Lock, 3/8-16
20 1713578 1 ROD, Mower Hitch
21 1715759 1 ROD, Latch
22 1713561 1 HITCH
23 1960519 1 NUT, Push, 1/2
24 156302 1 SPRING
