Simplicity REGENT 500 - Manual (Page 33)

Seat & Seat Deck – Early Models (1693074-1693104)
31 TP-400-2146-01-RG-SMA
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693074 Regent 14G
1693076 Regent 14G
1693080 Regent 14H
1693082 Regent 14H
1693084 Regent 16G
1693086 Regent 16G
1693088 Regent 16H
1693090 Regent 16H
1693092 514G, 14G
1693094 514H, 14H
1693098 516H, 16H
1693100 2514G, 14G
1693102 2514H, 14H
1693104 2516H, 16H
1 1718002 1 SEAT ASSEMBLY (Incl. Seat Cover, Ref. 2)
2 1714483 1 COVER, Seat
3 1713595 1 SLIDE, Seat
4 1931648 4 CAPSCREW, Whiz Lock Hex Hd, 5/16-18 x 1/2
5 1713594 1 PAN, Seat
6 1917372 2 NUT, Hex, Full, 5/16-18
7 1917356 2 LOCKWASHER, 5/16
8 1714358 2 BAR ASSEMBLY, Seat Pivot
9 1930591 6 CAPSCREW, Whiz Lock Hex Hd, 5/16-18 x 3/4
10 1713794 2 STOP, Rubber Seat
11 1714317 1 SEAT DECK, Orange
11 41714317 1 SEAT DECK, Red
12 1935255 2 SPEED NUT, Tinnerman Lug Type, 5/16-18
13 1931277 4 NUT, Hex Flange Whiz-Lock, 5/16-18
14 1714909 1 GUARD, Splash, Pod
15 1714908 1 CONTROL POD, Gear
16 1714542 1 CONTROL POD, Hydro
17 1960086 3 CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 5/8
18 1708008 1 CLAMP, Wire (Middle Bolt Only)
19 1919326 3 WASHER, 5/16
20 1666697 3 SPACER
21 1715047 1 CAP
22 1713597 1 LEVER, Seat Latch
23 159106 1 SPRING, Extension
24 1714318 2 SIDE PANEL, Seat Slide
25 1919438 2 NUT, Hex Nylon Lock, 5/16-18
26 1709256 2 WASHER
27 1704728 2 SPRING, Seat
28 1715768 1 PLATE, Spring Support
29 1931335 2 CARRIAGE BOLT, 5/16-18 x 1
30 1714771 1 SWITCH, Seat, Used with Seat P/N 1718002
