Electrical Group - Gear Models
25
TP-400-2146-01-RG-SMA
REF NO.
PART NO.
QTY.
DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693074
Regent 14HP Gear
1693076
Regent 14HP Gear-Export
1693084
Regent 16HP Gear
1693086
Regent 16HP Gear-Export
1693092
514G, 14HP Gear
1693100
2514G, 14HP Gear
1693323
Regent 14HP Gear
1693331
Regent 14HP Gear-Export
1693339
514G, 14HP Gear
1693345
2514G, 14HP Gear
1
1931333
1
CARRIAGE BOLT, 5/16-18 x 3/4
2
1713756
1
CLAMP, Battery
3
1919326
1
WASHER, Plain, 5/16
4
1919438
1
NUT, Hex Nylon Lock, 5/16-18
5
1704581
1
CAP, Vent, Battery
6
1685215
1
BATTERY
7
1704583
1
HOSE, Drain
8
1715014
2
TUBE, Shrink
9
1715011
1
WIRE ASSEMBLY, Transmission
10
1654634
1
SWITCH, Transmission
11
1715540
1
SEAL, O-Ring
12
101025
3
WASHER, 5/8
13
1714770
1
SWITCH, Pedal, N.C., Gray
14
1704379
1
SWITCH, Pedal, N.O., Black
15
1717163
2
KEY, Ignition
16
1715010
1
WIRE ASSEMBLY, Seat Switch
17
1717456
1
WIRING HARNESS, Main
18
1703799
1
SWITCH, Headlights
19
1716332
1
SWITCH, PTO
20
1703484
2
CABLE, (Solenoid to Starter & Battery to Ground)
21
122023
1
COVER, Terminal
22
1917356
2
LOCKWASHER, 5/16
23
1920263
2
NUT, Hex, 5/16-24 NF
24
1603618
1
CABLE, Battery, Positive
25
1677296
1
BOOT, Insulator
26
1921319
2
WASHER, 1/4
27
1923341
2
CAPSCREW, Hex Hd., 1/4-20 x 3/4
28
1916964
2
LOCKWASHER, 1/4
29
1916622
2
NUT, Hex, 1/4-20
30
932747
3
TIE
31
1685290
1
SOLENOID
32
1927429
1
CAPSCREW, Taptite Hex Washer Hd, 1/4-20 x 5/8
33
1665238
1
CIRCUIT BREAKER
34
1665237
1
WIRE ASSEMBLY
35
1716061
1
SWITCH, Ignition, 6-Pole
36
1960547
1
LOCKWASHER, Internal Tooth, 5/8
37
934683
1
CLIP, Wire
38
1717549
1
NUT, Hex, Flange, 5/8-32
39
1717550
1
COVER, Ignition
