Simplicity REGENT 500 - Manual (Page 37)

Hydro Models Wheels & Tires
35 TP-400-2146-01-RG-SMA
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693080 Regent 14HP Hydro
1693082 Regent 14HP Hydro (Ex)
1693088 Regent 16HP Hydro
1693090 Regent 16HP Hydro (Ex)
1693094 514H, 14HP Hydro
1693098 516H, 16HP Hydro
1693102 2514H, 14HP Hydro
1693104 2516H, 16HP Hydro
1693325 Regent 14HP Hydro
1693329 Regent 16HP Hydro
1693333 Regent 14HP Hydro (Ex)
1693337 Regent 16HP Hydro (Ex)
1693341 514H, 14HP Hydro
1693343 516H, 16HP Hydro
1693347 2514H, 14HP Hydro
1693349 2516H, 16HP Hydro
1 1717749 2 KEY
2 1716131 2 REAR WHEEL & TIRE ASSEMBLY - 16HP Models, 20x8.00-8 (Includes
Refs. 3, 4, & 5)
2 1716166 2 REAR WHEEL & TIRE ASSEMBLY - 14HP Models, 18x8.50-8 (Includes
Refs. 3, 4, & 5)
3 1715031 2 TIRE, 18 x 8.50-8” - 14HP Models
3 1716133 2 TIRE, 20 x 8.00-8” - 16HP Models
4 1716132 2 WHEEL, Metallic Gray, 8”, Rear
5 172353 4 VALVE STEM & CAP
6 960202 8 WASHER, 3/4 (Qty. 8 used on Simplicity models, 4 on AGCO-Allis &
Massey Ferguson Models)
7 1717451 2 SPACER
8 927794 2 E-RING
9 1714926 2 HUB CAP, 7-3/4” Black, Rear Scalloped (Simplicity Models)
10 1960114 2 WASHER , 3/4
11 1701435 4 RETAINER, Cap (AGCO-Allis & Massey Ferguson Models)
12 1676519 4 CAP, Axle (AGCO-Allis & Massey Ferguson Models)
13 1713466 2 FRONT WHEEL & TIRE ASSEMBLY - 14HP Models, 15x6.00-6 (Includes
Refs. 5, 14, 15, 16 & 17)
13 1716129 2 FRONT WHEEL & TIRE ASSEMBLY - 16HP Models, 15x6.50-6 (Includes
Refs. 5, 14, 15, 16 & 17)
14 1715032 2 WHEEL ASSEMBLY, Metallic Gray, 6”, Front (Includes Refs. 15 & 16)
15 1713167 4 BEARING
16 912808 2 FITTING, Grease
17 1715030 2 TIRE, 15 x 6.00-6” - 14HP Models
17 1716130 2 TIRE, 15 x 6.50-6” - 16HP Models
18 1664090 2 TUBE, Tire 6”, Front
19 1611710 2 KLIPRING, 3/4
20 1714925 2 HUB CAP, 5-3/4, Black, Front Scalloped (Simplicity Models)
