13 TP-400-2146-01-RG-SMA
REFERENCE Transaxle Service Parts — Peerless Model MST 205-515B (Gear Models)
1 772144 1 Transaxle Cover
2 780086A 2 Needle Bearing 5/8” ID
3 770128 1 Transaxle Case
4 776395 1 Countershaft
5 776409 1 Output Shaft
6 778364 1 Spur Gear (38 teeth)
6A 778365 1 Spur Gear (15 teeth-steel)
7 778330 1 Spur Gear (11 teeth-steel)
8 792136A 2 Shift Key
9 784352 1 Shift Collar
10 784378 1 Shift Rod & Fork
11 778334 1 Bevel Gear (30 teeth)
12 778309 1 Input Bevel Pinion (13 teeth)
13 778327 2 Bevel Gear (16 teeth-steel)(Incl. 14)
14 778327 2 Bevel Gear (16 teeth-steel)(Incl. 13)
15 778312A 1 Ring Gear (43 teeth)
17 786139 1 Drive Pin
18 786102 1 Spacer
20 792077 1 Ball 5/16” dia
21 792078 1 Set Screw 3/8-16 x 3/8”
22 792079 1 Spring
25 792073A 16 Screw 1/4-20 x 1-1/4”
25A 792177 2 Screw 1/4-20 X 1-3/8”
26 792125 4 Retaining Ring (pkg of 2)
27 792035 1 Retaining Ring
28 788040 1 Retaining Ring
29 780072 4 Washer
29A 780160 1 Washer
29B 780165 2 Thrust Washer
30 780108 4 Washer
31 780001 2 Washer (.056 wide) (USE AS NEEDED)
31A 780195 2 Flat Washer (.062 wide)
32 788083 1 Oil Seal 5/8”
34 780194 2 Bushing
35 780193 2 Flanged Bushing
35A 780197 2 Flanged Bushing 3/4”
36 790075 1 Brake Disk
37 790007 1 Brake Pad Plate
38 799021 2 Brake Pad (pkg of 2)
39 786026 2 Dowel Pin
40 792076A 1 Washer
41 790019 1 Brake Lever
42 792073A 1 Screw 1/4-20 x 1-1/4”
42A 792085A 1 Screw 1/4-20 x 2-1/4”
43 792075 1 Locknut 5/16-24
44 790025 1 Brake Pad Holder
45 786066 1 Spacer
46 786086 1 Brake Lever Bracket
47 774942 1 Axle (12-7/32” long)
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
Peerless transmission parts must be ordered through your local Tecumseh/Peerless distributor.
© Copyright 1998 Tecumseh Products Company. All Rights Reserved.
Reference Nos 48 through 180 are listed on the following pages.
The above parts group applies to the following Mfg. Nos.:
1693074 Regent 14HP Gear
1693076 Regent 14HP Gear-Export
1693084 Regent 16HP Gear
1693086 Regent 16HP Gear-Export
1693092 514G, 14HP Gear
1693100 2514G, 14HP Gear
1693323 Regent 14HP Gear
1693331 Regent 14HP Gear-Export
1693339 514G, 14HP Gear
1693345 2514G, 14HP Gear
