Simplicity REGENT 500 - Manual (Page 51)

44” Mower Deck - Housing, Arbors & Blades
49 TP-400-2146-01-RG-SMA
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693169 44” Mower Deck
1693188 44” Mower Deck
1693189 44” Mower Deck
1 1714419 3 NUT, Hex, Flange, 9/16-8
2 1713675 6 WASHER, Belleville
3 1713161 2 PULLEY, RH Arbor & LH Arbor
4 1713616 1 HUB, Adapter (LH)
5 1655729 3 COVER, Arbor Housing
6 108202 3 BEARING, Upper
7 1715724 3 SPACER, Sleeve, Upper Bearing
8 1715723 3 SPACER, Arbor, Internal
9 1705897 3 BEARING, Lower
10 1707335 3 GASKET, Foam
11 1713338 3 ARBOR HOUSING ASSEMBLY (Incl. Fitting Ref. 12)
12 1704314 3 FITTING, Grease
13 1716090 1 COVER, Arbor (LH)
14 1664847 3 CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 3/4
15 1713619 3 WASHER
16 1713612 1 SHAFT, Arbor (LH)
17 1713196 3 SHIELD, Grass, Lower
18 1704100 3 BLADE, Mower, 16-1/8”
19 1713089 3 WASHER, Hex
20 1656916 3 WASHER, Spring
21 923471 3 CAPSCREW, Hex, Hd., 7/16-14 x 1-1/4
22 1713609 1 SHAFT, Arbor (RH)
23 1686681 1 HOUSING ASSEMBLY, Orange
23 61686681 1 HOUSING ASSEMBLY, Black
24 1715673 1 COVER, Arbor (RH)
25 1931318 2 CARRIAGE BOLT, 1/4-20 x 7/8
26 1960518 2 NUT, Push On
27 1960353 2 WASHER, Plain, 1/4
28 1704873 1 CLAMP
29 1919326 1 WASHER, Plain, 5/16
30 1705080 1 SPRING, Deflector Retaining
31 1916964 2 LOCKWASHER, 1/4
32 1916622 2 NUT, Hex, 1/4-20, UNC
33 1706709 1 ROD, Deflector, Front
34 1705115 1 PLUG, Hole
35 1705449 1 DEFLECTOR, Plastic
36 1713613 1 HUB, Pulley (RH)
37 1718021 1 PULLEY, Arbor (Center)
38 1713614 1 HUB, Pulley (Center)
39 1713610 1 SHAFT, Arbor (Center)
