44” Mower Deck - Height Adjustment & Gauge Wheels
53
TP-400-2146-01-RG-SMA
REF NO.
PART NO.
QTY.
DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693169
44” Mower Deck
1693188
44” Mower Deck
1693189
44” Mower Deck
1
1664847
7
CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 3/4
2
1716555
1
BRACKET, Upstop
3
1921977
2
CAPSCREW, Hex Hd, 5/16-18 x 1-1/4
4
1960044
8
WASHER, 5/16
5
1714553
1
BRACKET, “U”
6
1710703
2
SPACER
7
1923362
4
NUT, Hex Lock, 5/16-18
8
1960074
1
CLIP, Spring
9
1714529
1
ROD, Transport
10
1717145
1
ARM, Rear
11
1960223
1
CARRIAGE BOLT, 5/16-18 x 1-1/4
12
1714876
1
GRIP
13
1717658
1
ARM, Adjustment
14
1931353
1
CARRIAGE BOLT, 3/8-16 x 1-3/4
15
1714263
1
SPRING
16
1930645
2
NUT, Hex Flange Whiz Lock, 3/8-16
17
1917372
2
NUT, Hex, Full, 5/16-18
18
1917356
2
LOCKWASHER, 5/16
19
1921332
1
CAPSCREW, Hex Hd, 5/16-18 x 3/4
20
1717109
1
QUADRANT
21
1715671
1
ARM ASSEMBLY, Rocker
22
1665374
2
STRAP
23
1714879
1
ECCENTRIC
24
1924874
1
WASHER, 5/16
25
1916950
1
NUT, Hex, 3/8
26
1916965
1
WASHER, Lock, 3/8
27
1704082
1
NUT, Adjuster
28
1931352
1
CARRIAGE BOLT, 3/8-16 x 1-1/2
29
1960373
4
CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 1
30
1960236
4
SPACER
31
1921333
2
CAPSCREW, Hex Hd, 5/16-18 x 1
32
158399
4
E-RING, 1/2
33
1960027
4
WASHER, 1/2
34
1714760
5
WHEEL, Gauge
35
1714877
2
ARM ASSEMBLY
36
1960288
2
PIN
37
1960221
2
CLIP, Hairpin
38
1714878
2
ARM ASSEMBLY, Adjustable
39
1715608
2
STRAP
40
1714881
1
BRACKET, Gauge Wheel
41
1715624
1
ROD, Mower Hitch
42
1960519
1
NUT, Push, 1/2
43
1924940
4
WASHER, 3/8
44
1611705
1
SPACER
45
1718019
1
ARM, Pitch
46
1667812
1
SPACER
47
1923701
1
CAPSCREW, Hex Hd., 3/8-16 x 2, Grade 5
