Hood, Dash & Fuel Tank
29
TP-400-2146-01-RG-SMA
REF NO.
PART NO.
QTY.
DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693074
Regent 14G
1693076
Regent 14G
1693080
Regent 14H
1693082
Regent 14H
1693084
Regent 16G
1693086
Regent 16G
1693088
Regent 16H
1693090
Regent 16H
1693092
514G, 14G
1693094
514H, 14H
1693098
516H, 16H
1693100
2514G, 14G
1693102
2514H, 14H
1693104
2516H, 16H
1693323
Regent 14G
1693325
Regent 14H
1693329
Regent 16H
1693331
Regent 14G
1693333
Regent 14H
1693337
Regent 16H
1693339
514G, 14G
1693341
514H, 14H
1693343
516H, 16H
1693345
2514G, 14G
1693347
2514H, 14H
1693349
2516H, 16H
1
1674231
1
FITTING, Fuel
2
1654930
1
GROMMET, Fuel Fitting
3
1714472
1
FUEL TANK
4
1714020
1
CAP, Fuel Tank
5
1715044
1
STRAP
6
1704351
1
FASTENER, Plastic, Ratchet
7
1919438
2
NUT, Hex Nylon Lock, 5/16-18
8
1960353
A/R
WASHER, 1/4
9
1960368
4
PAL NUT, 1/4-20
10
1960295
11
CAPSCREW, Whiz Lock Hex Hd, 1/4-20 x 5/8
11
1714538
1
BULKHEAD
12
1925003
4
CAPSCREW, Taptite Hex Washer Hd, 1/4-20 x 1/2
13
1715495
1
GROMMET, Strip
14
1714769
1
DASHBOARD
15
172434
2
CLIP
16
1714350
1
PANEL, Side, LH, Orange
16
41714350
1
PANEL, Side, LH, Red
17
1714353
1
LIGHT BAR ASSEMBLY (Incl. Ref. Nos. 18, 19, 20 & 21)
18
1714787
2
SOCKET, Bulb
19
1714786
1
BEZEL
20
1677371
2
BULB, #1156
21
1714785
1
LENS
22
1920397
10
NUT, Hex, Nylon Lock, 1/4-20
23
1714352
1
GRILLE, Orange
23
41714352
1
GRILLE, Red
24
1921319
2
WASHER, Plain, 1/4
25
1704626
2
SPACER, Plastic, Hood Pivot
26
1704628
2
CLIP, Pivot Spacer Retaining
27
1714875
2
HINGE, Hood
28
1710703
2
SPACER
29
1922837
2
CAPSCREW, Hex Hd, 1/4-20 x 1-1/2
30
1930595
2
CAPSCREW, Whiz Lock Hex Hd, 5/16-18 x 1-1/4
31
1705248
2
SPACER, Steel, Hood Pivot, Grooved
32
1705249
2
SPACER, Steel, Hood Pivot
33
1714349
1
HOOD, Orange
33
41714349
1
HOOD, Red
34
1714351
1
PANEL, Side, RH, Orange
35
41714351
1
PANEL, Side, RH, Red
