Simplicity REGENT 500 - Manual (Page 47)

38” Mower Deck - Belt, Idler Arm & Hitch
45 TP-400-2146-01-RG-SMA
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
* Not Serviced Separately
The above parts group applies to the following Mfg. Nos.:
1693078 38” Mower Deck
1693079 38” Mower Deck
1693218 38” Mower Deck-Export
1 1928957 2 CAPSCREW, Hex Hd, 3/8-16 x 2-3/4
2 1922755 4 WASHER, Plain, 3/8
3 1677135 1 GUARD, Spring
4 1666294 1 SPACER
5 1685150 1 PULLEY ASSEMBLY
6 1665835 1 GRIP, Lever
7 1916965 1 LOCKWASHER, 3/8
8 1916950 1 NUT, Hex, 3/8-16
9 1715435 1 SPRING
10 1919439 3 NUT, ESNA Hex Lock, 3/8-16
11 1924356 2 WASHER , 3/8
12 1663114 2 BUSHING
13 912808 1 FITTING, Grease
14 * 1 CLUTCH LEVER ASSEMBLY
15 1657242 1 SPACER
16 1930645 1 NUT, Hex Flange Hd, 3/8-16, 2-Way Lock
17 1924940 2 WASHER, Plain, 3/8
18 157081 2 SPACER
19 1921969 2 CAPSCREW, Hex Hd, 3/8-16 x 1-1/2
20 1713561 1 HITCH
21 1713578 1 ROD, Mower Hitch
22 1715759 1 ROD, Latch
23 1960519 1 NUT, Push, 1/2
24 156302 1 SPRING
25 1704520 1 CLUTCH LEVER ASSEMBLY w/ BUSHINGS, (Included Ref. No. 12, 13, and
14)
26 1716854 1 V-BELT
