Seat & Seat Deck – Later Models (1693323-1693349)
33 TP-400-2146-01-RG-SMA
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
Optional arm rest kit avaliable under Whole Goods Part Number 1693427
The above parts group applies to the following Mfg. Nos.:
1693323 Regent 14G
1693325 Regent 14H
1693329 Regent 16H
1693331 Regent 14G
1693333 Regent 14H
1693337 Regent 16H
1693339 514G, 14G
1693341 514H, 14H
1693343 516H, 16H
1693345 2514G, 14G
1693347 2514H, 14H
1693349 2516H, 16H
1 1718851 1 SEAT ASSEMBLY
2 1931335 2 CARRIAGE BOLT, 5/16-18 x 1
3 1713595 1 SLIDE, Seat
4 1931648 4 CAPSCREW, Whiz Lock Hex Hd, 5/16-18 x 1/2
5 1718985 1 PAN, Seat
6 1917372 2 NUT, Hex, Full, 5/16-18
7 1917356 2 LOCKWASHER, 5/16
8 1713758 2 BAR, Seat Pivot
9 1930591 6 CAPSCREW, Whiz Lock Hex Hd, 5/16-18 x 3/4
10 1713794 2 STOP, Rubber Seat
11 1714317 1 SEAT DECK, Orange
11 41714317 1 SEAT DECK, Red
12 1935255 2 SPEED NUT, Tinnerman Lug Type, 5/16-18
13 1931277 4 NUT, Hex Flange Whiz-Lock, 5/16-18
14 1714909 1 GUARD, Splash, Pod
15 1714908 1 CONTROL POD, Gear
16 1714542 1 CONTROL POD, Hydro
17 1960086 3 CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 5/8
18 1708008 1 CLAMP, Wire (Middle Bolt Only)
19 1919326 3 WASHER, 5/16
20 1666697 3 SPACER
21 1715047 1 CAP
22 1713597 1 LEVER, Seat Latch
23 159106 1 SPRING, Extension
24 1714318 2 SIDE PANEL, Seat Slide
25 1919438 2 NUT, Hex Nylon Lock, 5/16-18
26 1709256 2 WASHER
27 1704728 2 SPRING, Seat
28 1715768 1 PLATE, Spring Support
29 1718981 1 SWITCH, Seat, Used with Seat P/N 1718851
