21 TP-400-2146-01-RG-SMA
Tuff Torq K-56 Transaxle SERVICE PARTS (Hydro Models)
1 1718064 1 UPPER HOUSING, Complete.
2 N/A 1 UPPER HOUSING
3 N/A 2 BUSHING, 19.05
4 1718111 2 SEAL, (S19 x 32 x 8)
5 1718074 1 PUMP SHAFT
6 1708651 1 SEAL, TC153507
7 1718076 2 RING, E15
8 1708650 1 RING, 35
9 1708673 1 BEARING, 6202C3
10 1718057 1 SHAFT, Bypass
11 1718058 1 BY-PASS ARM
12 1708691 2 PACKING, P10A
13 1718055 1 SEALING CAP, 50
14 1718054 1 SPRING, (Filter)
15 1718053 1 FILTER, 25-Disc
16 1718052 1 VENT VALVE, 15
17 N/A 1 CAP, Vent Valve
18 N/A 1 BODY, Vent Valve
19 1718117 1 SHAFT, Brake
20 1718121 1 PACKING, P29
21 1718118 1 CAM, Brake
22 1718120 1 SEAL, TC162606
23 1718116 1 ARM, Brake
24 1718119 1 PLATE, Brake
25 1718122 2 BOLT, 8 X 30
26 1718060 1 DISK SPRING, 10
27 1718061 1 RING, 10
28 1718094 1 FULCRUM, Eccentric
29 1718097 1 PIN, 6.0A x 25
30 1718092 1 CONTROL ARM
31 1718093 1 COLLAR, Control
32 1718095 1 SPRING, Torsion
33 1718100 1 PIN, 6.0A x 40
34 1718101 1 LEVER, Control
35 1718090 1 SEAL, TC162606
36 1718091 1 SHAFT, Control
37 1708692 1 NUT, 12
38 1708689 1 WASHER, 12
39 1718098 2 PACKING, P 14
40 1718109 1 SHAFT, Axle
41 1718110 2 BUSHING, 19 x 21
42 1718112 2 WASHER, THRUST
43 1718113 2 RING, 17
44 1718103 1 DIFF. GEAR KIT
45 N/A 2 DIFF. SIDE GEAR
46 1718102 1 GEAR, Final
47 N/A 2 DIFF. PINION
48 N/A 2 PIN, 13 x 22.5
49 1718108 1 SHAFT, Axle, LH
50 1718104 1 SHAFT, Reduction
51 1718105 2 WASHER, 12 x 32 x 3.2
52 1718107 1 PINION, Final
REF NO. PART NO. QTY. DESCRIPTION
Footnotes: Components marked “N/A” are not serviced separately.
Order the complete assembly that the component is a part of.
The above parts group applies to the following Mfg. Nos.:
1693080 Regent 14HP Hydro
1693082 Regent 14HP Hydro (Ex)
1693088 Regent 16HP Hydro
1693090 Regent 16HP Hydro (Ex)
1693094 514H, 14HP Hydro
1693098 516H, 16HP Hydro
1693102 2514H, 14HP Hydro
1693104 2516H, 16HP Hydro
1693325 Regent 14HP Hydro
1693329 Regent 16HP Hydro
1693333 Regent 14HP Hydro (Ex)
1693337 Regent 16HP Hydro (Ex)
1693341 514H, 14HP Hydro
1693343 516H, 16HP Hydro
1693347 2514H, 14HP Hydro
1693349 2516H, 16HP Hydro
