Appendix B: BIOS POST Codes
B-1
Appendix B:
BIOS POST Codes
This section lists the POST (Power On Self Testing) Codes for the Award BIOS.
POST (hex) Defi nition
CFh Test CMOS R/W functionality
C0h Early chipset initialization
- Disable shadow RAM
- Disable L2 cache (socket 7 or below)
- Program basic chipset registers
C1h Detect memory
- Auto detection of DRAM size, type and ECC
- Auto detection of L2 cache (socket 7 or below)
C3h Expand compressed BIOS code to DRAM
C5h Call chipset hook to copy BIOS back to E000 & F000 shadow RAM
0h1 Expand the Xgroup codes located in physical address 1000:0
02h Reserved
03h Initial Superio_Early_Init switch
04h Reserved
05h 1. Blank out screen
2. Clear CMOS error fl ag
06h Reserved
07h 1. Clear 8042 interface
2. Initialize 8042 self-test
08h 1. Test special keyboard controller for Winbond 977 series Super I/O chips
2. Enable keyboard interface
09h Reserved
0Ah 1. Disable PS/2 mouse interface
2. Auto detect ports for keyboard & mouse followed by a port & interface swap (optional)
3. Reset keyboard for Winbond 977 series Super I/O chips
0Bh Reserved
0Ch Reserved
0Dh Reserved
0Eh Test F000h segment shadow to see whether it is R/W-able or not. If test fails, keep beeping the
speaker.
0Fh Reserved
10h Auto detect fl ash type to load appropriate fl ash R/W codes into the run time area in F000 for ESCD
& DMI support
11h Reserved
