5-22

S

UPER

S

ERVER 5014C-MF User's Manual

Floppy Drive Connector

Pin Defi nitions (Floppy)

Pin# Defi nition Pin # Defi nition

1

Ground

2

FDHDIN

3

Ground

4

Reserved

5

Key

6

FDEDIN

7

Ground

8

Index

9

Ground

10

Motor Enable

11

Ground

12

Drive Select B

13

Ground

14

Drive Select B

15

Ground

16

Motor Enable

17

Ground

18

DIR

19

Ground

20

STEP

21

Ground

22

Write Data

23

Ground

24

Write Gate

25

Ground

26

Track 00

27

Ground

28

Write Protect

29

Ground

30

Read Data

31

Ground

32

Side 1 Select

33

Ground

34

Diskette

Floppy Connector

The fl oppy connector is located

between the IDE slot and the

IPMI Socket. See the table below

for pin defi nitions.
