7-4
S UPER S ERVER 5014C-MF User's Manual
IDE HDD Auto-Detection
This option allows the user to determine the manner in which the AwardBIOS
sets the settings for IDE Channel 0 to IDE Channel 3 Master Devices. The
options are "None", "Auto" and "Manual."
IDE Channel 0 to IDE Channel 3 Master
Press the key to activate the 'IDE HDD Auto-Detection" function, which
will allow the BIOS to automatically detect the status of the IDE HDD installed
in the system, such as the size, the number of cylinders, the confi gurations of
items such as Head, Precomp, Landing Zone and Sector. The options are None,
Auto and Manual.
Access Mode
This item determines the location through which the AwardBIOS accesses the IDE
Primary Master Device. The settings are "CHS", "LBA", "Large", and "Auto".
Halt On
This item allows the user to select the situation in which the BIOS will stop the
POST process and notify you about the status of the system. The settings are
"All Errors", "No Errors", "All, But Keyboard", "All, But Diskette", and "All, But
Disk/Key".
Total Physical Memory/Total System Resources/Total Available
Memory
These are displays that inform you how much of each type of memory is recognized
as being present in the system.
