S UPER S ERVER 5014C-MF User's Manual
Figure 5-4. P8SCT Layout
(not drawn to scale)
Note: Jumpers not indicated are for test purposes only.
5-8 Motherboard Details
Keyboard/
Mouse
FAN5
J14
USB1/2
COM1
Parallel Port
VGA
ATX Power Connector
CPU
LGA775
JLAN1
JLAN2
DIMM1A
DIMM1B
+12V PWR
E7221
North Bridge
JF1
PCI-X #6 (133 MHz)
BATTERY
BIOS
S
U
P
E
R
P
8
S
C
T
JPWAKE1
JWD
DIMM2A
DIMM2B
USB5/6
BANK1
BANK2
JK1
PCI #5 (33 MHz)
Kybd/Mouse
JL1
FAN1
JP3
FAN3
J9
JSLED
SPEAKER
PXH-V
USB3/4
JWOR
Floppy
BCM5721
BCM5721
ICH6R
South Bridge
JWOL
PW1
PW2
JFSB2/JFSB1
PCI #5 (33 MHz)
PCI #4 (33 MHz)
PCI #3 (33 MHz)
PCI #2 (33 MHz)
PCI #1 (33 MHz)
COM2 IDE
FAN4
IPMI
JLED
JPF
FAN2
SA
T
A
#0 / SA
T
A#1 / SA
T
A
#2 / SA
T
A#3
JPL1
JPL2
JP1
JP2
LE1
J11
JPUSB1
JPUSB2
