Chapter 5: Advanced Motherboard Setup
5-19
JLAN1/JLAN2 Enable/
Disable
Change the setting of jumper JPL1 to
enable or disable the JLAN1 port and
JPL2 to enable or disable the JLAN2
port on the motherboard. See the
table on the right for jumper settings.
The default setting is enabled.
Watch Dog Enable/Disable
JWD enables the Watch Dog function,
a system monitor that takes action
when a software application freezes
the system. Jumping pins 1-2 will
have WD reboot the system if a pro-
gram freezes. Jumping pins 2-3 will
generate a non-maskable interrupt for
the program that has frozen. See the
table on the right for jumper settings.
Watch Dog must also be enabled in
BIOS.
Note: when Watch Dog is enabled, the user must
write their own application software to disable the
Watch Dog Timer.
JLAN1/2 Enable/Disable
Jumper Settings (JPL1/2)
Jumper Setting Defi nition
Pins 1-2 Enabled
Pins 2-3 Disabled
Watch Dog
Jumper Settings (JWD)
Jumper Setting Defi nition
Pins 1-2 Reset
Pins 2-3 NMI
Open Disabled
SMBus to PCI
Jumpers JP1, JP2 allow you to con-
nect PCI/PCI-X slots to the System
Management Bus. The default setting
is “Open” to disable the connection.
See the table on the right for jumper
settings.
SMBus to PCI
Enable/Disable
Jumper Settings (JP1/JP2)
Jumper Setting Defi nition
Closed Enabled
Open Disabled
