Chapter 5: Advanced Motherboard Setup
5-15
Wake-On-LAN
The Wake-On-LAN header is des-
ignated JWOL on the motherboard.
See the table on the right for pin
defi nitions. You must enable the LAN
Wake-Up setting in BIOS to use this
function. (You must also have a LAN
card with a Wake-On-LAN connector
and cable to use this feature.)
Chassis Intrusion
The Chassis Intrusion header is des-
ignated JL1. See the board layout for
the location of JL1 and the table on
the right for pin defi nitions.
Universal Serial Bus (USB)
There are two Universal Serial Bus
ports located on the I/O panel and
four additional USB headers located
on the motherboard. The headers,
labeled USB3/4 and USB5/6, can be
used to provide front side USB access
(cables not included). See the tables
on the right for pin defi nitions.
Chassis Intrusion
Pin Defi nitions (JL1)
Pin# Defi nition
1 Intrusion Input
2 Ground
Universal Serial Bus
Pin Defi nitions (USB0/1)
USB0/1/3/5
Pin # Defi nition USB4/6
Pin # Defi nition
1 +5V 1 +5V
2 PO- 2 PO-
3 PO+ 3 PO+
4 Ground 4 Ground
5 N/A 5 Key
Wake-On-LAN
Pin Defi nitions
(JWOL)
Pin# Defi nition
1 +5V Standby
2 Ground
3 Wake-up
JLAN1/2 (Ethernet Ports)
Two Ethernet ports (designated
JLAN1 and JLAN2) are located
beside the VGA port on the I/O
backplane. These ports accept
RJ45 type cables.
