7-8
S UPER S ERVER 5014C-MF User's Manual
7-4.3 I/O Device Confi guration
Onboard Serial Port1/Onboard Serial Port2
This setting allows the user to set the address and the corresponding IRQ for
Serial Port1 and Serial Port 2. The options are "Disabled" , "3F8/IRQ4", "2F8/
IRQ3", "3E8/IRQ4", "2E8/IRQ3", and "Auto". The default setting for Serial Port1
is "3F8/IRQ4" and the default for Port 2 is "2F8/IRQ3".
Onboard Parallel Port
This setting allows the user to set the address and the corresponding IRQ for the
onboard parallel port. The options are "Disabled", "378/IRQ7", "278/IRQ5" and
"3BC/IRQ7".
Parallel Port Mode
This setting sets the mode for the onboard Parallel port. The options are "SPP,"
"EPP", "ECP" "ECP+EPP" and "Normal".
EPP Mode Select
This setting allows the user to select the EPP port type. The options are "EPP
1.9" and "EPP 1.7".
ECP Mode Use DMA
This setting allows the user to select the DMA channel for the ECP mode (port) to
use. The options are "1" and "3".
Power On Function
This setting allows the user to decide which method to use to power on the system.
The options are "Password", "Hot Key", "Mouse Left", "Mouse Right", "Any Key",
and "Button Only".
KB Power On Password
This setting allows the user to enter the Password when the system is powered
on via keyboard.
Hot Key Power On
This setting allows the user to decide which hot-keys to use in order to power on
the system. The options are "Ctrl-F1", "Ctrl-F2, Ctrl-F3", "Ctrl-F4", "Ctrl-F5", "Ctrl-
F6", "Ctrl-F7", and "Ctrl-F8".
