Maximum Payload Size
This setting allows the BIOS to set the maximum TLP Payload size for the PCI
Express devices in the system. The options are: "128 (bytes)", "256 (bytes)", "512
(bytes)", "1024 (bytes)", "2048 (bytes)", and "4096 (bytes)".
PCI Express Root Port Function
PCI Express Port 1/PCI Express Port 2/PCI Express Port 3/PCI
Express Port 4
Select "Enabled" to enable the PCI Express Root Port Functions for the PCI
Express port specifi ed. The options are: "Disabled", "Enabled", and "Auto".
PCI-E Compliance Mode
This features allows the BIOS to set the version of PCI-E Compliance Mode for
the system. The options are: "v.1.0a" and "v.1.0".
PCI-X Frequency
This features allows the user to set the PCI-X slot frequency. The options are: "Auto,
PCI-33 MHz, PCI-66 MHz, PCIX-66 MHz, PCI-X 100 MHz and PCI-X 133 MHz."
