Reset Connector
The reset connector is located on pins
3 and 4 of JF1 and attaches to the
reset switch on the computer chas-
sis. See the table on the right for pin
defi nitions.
PW_ON Connector
The PW_ON connector is on pins 1
and 2 of JF1. This header should
be connected to the chassis power
button. See the table on the right for
pin defi nitions.
5-9 Connector
Defi nitions
Power Supply Connectors
The primary power supply connector
(PW1) on the P8SCT meets the SSI
(Superset ATX) 24-pin specifi cation.
Refer to the table on the right for the
pin defi nitions of the ATX 24-pin power
connector. You must also connect the
4-pin (PSW2) processor power con-
nector to your power supply. Refer
to the table below right for the PW2
(12V) connector.
Important: you must connect PW2 to
your power supply to meet the ATX
safety requirements.
Required Connection
+12V 4-pin Power
Pin Defi nitions (PW2)
Pins Defi nition
1 & 2 Ground
3 & 4 +12V
ATX Power 24-pin Connector
Pin Defi nitions (PW1)
Pin# Defi nition Pin # Defi nition
13 +3.3V 1 +3.3V
14 -12V 2 +3.3V
15 COM 3 COM
16 PS_ON 4 +5V
17 COM 5 COM
18 COM 6 +5V
19 COM 7 COM
20 Res (NC) 8 PWR_OK
21 +5V 9 5VSB
22 +5V 10 +12V
23 +5V 11 +12V
24 COM 12 +3.3V
Reset Button
Pin Defi nitions (JF1)
Pin# Defi nition
3 Reset
4 Ground
Power Button
Pin Defi nitions (JF1)
Pin# Defi nition
1 PW_ON
2 Ground
