5-20

S

UPER

S

ERVER 5014C-MF User's Manual

PCI-X Slot Speed Select

JP3 allows you to select the Frequency

for the PCI-X slot. The default setting

is Closed. (Please do not change the

default setting.) See the table on the

right for pin defi nitions.

PCI-X Slot Speed Select

Jumper Settings (JP3)

Jumper Setting Defi nition

Open

133 MHz

Closed

100 MHz

CPU Front Side Bus Speed

JFSB1 and JFSB2 allow you to set

the Front Side Bus Frequency. See

the table on the right for pin defi nitions.

(The default setting is Auto and should

not be changed.)

CPU Front Side Bus Speed

Pin Defi nitions

(JFSB1/JFSB2)

JFSB1

JFSB2 Defi nition

Pins 1-2

Pins 1-2

Auto

Pins 2-3

Pins 2-3

266 MHz

Pins 2-3

Open

200 MHz

Open

Open

166 MHz

Open

Pins 2-3

133 MHz

Note: Clock values are shown, employ a 4x

multiplier for front side bus speed. This jumper

setting should remain on Auto.

5-11 Onboard Indicators

JLAN1/JLAN2 LEDs

The Ethernet ports (located beside

the VGA port) have two LEDs. On

each Gb LAN port, the yellow (right)

LED indicates activity while the left

LED may be green, orange or off to

indicate the speed of the connection.

See the table on the right for the func-

tions associated with the left (activity

speed) LED.

JLAN Right LED

Connection Speed Indicator

LED Color Defi nition

Off

10 MHz

Green

100 MHz

Amber

1 GHz
