Anti-Tip Bracket Installation

WOOD FLOOR APPLICATIONS

Use the four #12 x 2

1

/

2

" wood screws and the four

1

/

4

"

flat washers provided. Drill pilot holes

3

/

16

" (5) diameter

maximum, and be sure that the screws penetrate through

the flooring material and into the wall plate a minimum of

3

/

4

" (19). Be sure that the screws hold tight. Refer to the

illustration below.

CONCRETE FLOOR APPLICATIONS

Use the two

3

/

8

" x 3

3

/

4

" concrete wedge anchors, two

#12 x 2

1

/

2

" wood screws and two

1

/

4

" flat washers

provided. Be sure that the anchors and screws hold tight.

Refer to the illustration below.

IMPORTANT NOTE:

In some installations the subflooring

or finished floor may require angling the wood screws

used to fasten the anti-tip bracket to the back wall.

Models 424 and 424FS Installation

9

subzero.com

Make sure that there are no electrical wires in the area

which the screws could penetrate.

12

3

/

16

"

(310)

12

3

/

16

"

(310)

24"

(610)

CL

FINISHED FLOORING

UNDERLAYMENT

WALL PLATE

SUBFLOORING

WOOD FLOOR

Wood floors.

Concrete floors.

24"

(610)

CL

1

1

/

2

"

min

(38)

12

3

/

16

"

(310)

12

3

/

16

"

(310)

FINISHED FLOORING

UNDERLAYMENT

WALL PLATE

SUBFLOORING

CONCRETE

FLOOR

INSTALL CONCRETE WEDGE ANCHORS:

1) Drill a

3

/

8

" (10) diameter hole any depth exceeding the

minimum embedment. Clean the hole or continue

drilling additional depth to accommodate drill fines.

Use a carbide drill bit manufactured within ANSI

B94.12-77.

2) Assemble the washer and nut flush with the end of

anchor to protect threads. Drive the anchor through the

material to be fastened until the washer is flush with

the surface material.

3) Expand the anchor by tightening the nut 3–5 turns past

hand-tight position or to 25 foot-pounds of torque.

Always wear safety glasses and use other necessary

protective devices or apparel when installing or

working with anchors.

Anchors are not recommended for use in lightweight

masonry material such as block or brick, or for use in

new concrete which has not had sufficient time to cure.

The use of core drills is not recommended to drill holes

for the anchors.
