– 60 –
• Scene No. (1st byte)
This command is used to specify the scene No. to be stored.
• Function 1, 2 (10, 11th byte)
This command is used to specify the function to implement recalling at the event of scene recall with the two 8-bit data.
When you want to recall the scene, set the corresponding bit to 1. When you do not want to recall the scene, set the corresponding bit
to 0.
If bit 5 (Clear) of the function 1 is 1, the scene memory is cleared and the scene will not be recalled.
Bit-6 and bit-7 of the function 1 and bit-5 to bit-7 of the function 2 are fixed all the time.
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
0 1 Clear ROUTING AV INPUT INPUT INPUT
SELECTOR FADER MUTING FUNCTION
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
0 1 0 FADER GROUP OUTPUT OUTPUT OUTPUT
GROUP MUTING FADER MUTING FUNCTION
Example: When setting the respective parameters as shown below.
Scene No. : 1
Index : START
Function 1,2 : All recall
43[H] 53[H] 54[H] 52[H] 31[H] 53[H] 54[H] 41[H] 52[H] 54[H] 20[H] 20[H] 20[H] 5F[H]
5F[H] 0D[H]
(‘C S T R 1 S T A R T s s s _ _ CR’)
“s” indicates the space.
SCENE No. SCENE No.
1 31[H] ( ‘1’ ) 11 3B[H] ( ‘;’ )
2 32[H] ( ‘2’ ) 12 3C[H] ( ‘<’ )
3 33[H] ( ‘3’ ) 13 3D[H] ( ‘=’ )
4 34[H] ( ‘4’ ) 14 3E[H] ( ‘>’ )
5 35[H] ( ‘5’ ) 15 3F[H] ( ‘?’ )
6 36[H] ( ‘6’ ) 16 40[H] ( ‘@’ )
7 37[H] ( ‘7’ ) 17 41[H] ( ‘A’ )
8 38[H] ( ‘8’ ) 18 42[H] ( ‘B’ )
9 39[H] ( ‘9’ ) 19 43[H] ( ‘C’ )
10 3A[H] ( ‘:’ ) 20 44[H] ( ‘D’ )
