About Your Phone, Battery and SIM Card 17 English
Charging Your Battery Using the Travel
Charger
1 While holding the i2000 with its front toward you, insert the
accessory connector (with the logo facing you) into the slot
on the bottom of the i2000 until you hear a click.
2 Attach the adapter to the travel charger transformer if
applicable. While charging in the USA/Canada, remove the
adapter and flip up the prongs.
3 Plug the travel charger transformer into an AC wall outlet. The
power light (green LED) on the travel charger transformer
comes on.
Travel Charger Operating Specifications
Input voltage range: 90-264 VAC @ 50/60 Hz.
Operating temperature range: 0°C to +50°C
Desktop Charging Your Battery
1 Plug the flat end of the power supply cord, with the logo
facing down, into the receptacle labelled “Charging” on the
back of the charger.
2 Plug the transformer end of the power supply cord into a
standard AC wall outlet.
3 Insert an i2000 with an attached battery, into the charger's
front pocket. This is done by inserting the bottom of the i2000
into the pin connector in the bottom of the charger's front
pocket.
Travel Charger
Transformer
Accessory Connector
Rear Pocket Front Pocket
Pin Connector Power Supply Cord
Receptacle
LED
Indicators
