Resolution

Mode

Aspect ratio

Refresh rate (Hz) “Match Input”

appearance

800 × 600

VGA 72

4:3

72.809

Pillarbox

800 x 600

VGA 75

4:3

75

Pillarbox

800 × 600

VGA 85

4:3

85.008

Pillarbox

800 × 600

SVGA 56

4:3

56.25

Pillarbox

800 × 600

SVGA 60

4:3

60.317

Pillarbox

800 × 600

SVGA 72

4:3

72.188

Pillarbox

800 × 600

SVGA 75

4:3

75

Pillarbox

800 × 600

SVGA 85

4:3

85.061

Pillarbox

832 × 624

MAC 16"

4:3

74.55

Pillarbox

1024 × 768

XGA 60

4:3

60.004

Pillarbox

1024 × 768

XGA 70

4:3

70.069

Pillarbox

1024 × 768

XGA 75

4:3

75.029

Pillarbox

1024 × 768

XGA 85

4:3

84.997

Pillarbox

1024 × 768

MAC 19"

4:3

74.7

Pillarbox

1152 × 864

SXGA 75

4:3

75

Pillarbox

1280 × 768

WXGA 60

1.67:1

60

Letterbox

1280 × 960

Quad VGA 60

4:3

60

Letterbox

1280 × 960

Quad VGA 85

4:3

85.002

Letterbox

1280 × 960

SXGA3 60

5:4

60.02

Pillarbox

1280 × 1024

SXGA3 75

5:4

75.025

Pillarbox

1280 × 1024

SXGA3 85

5:4

85.024

Pillarbox

1600 × 1200

SXGA+

4:3

59.978

Pillarbox

1600 × 1200

UXGA_60

4:3

60

Pillarbox

HD and SD signal format compatibility

The following tables list the projector’s high definition and standard definition format signal

compatibility, which you can adjust by using the aspect ratio commands described in Adjusting

projector settings on page 24.

Signal format

Aspect ratio

Horizontal
frequency (kHz)

Vertical
frequency (Hz)

“Match Input”
appearance

480i (525i)

4:3

15.73

59.94

Full screen

480p (525p)

4:3

31.47

59.94

Full screen

576i (625i)

5:4

15.63

50

Pillarbox

576p (625p)

5:4

31.25

50

Pillarbox

720p (750p)

16:9

45

59.94

Letterbox

720p (750p)

16:9

37.5

50

Letterbox

1080i (1125i)

16:9

33.75

59.94

Letterbox

1080i (1125i)

16:9

28.13

50

Letterbox

1080p (1125p)

16:9

67.5

59.94

Letterbox

1080p (1125p)

16:9

56.25

50

Letterbox
