Chapter 2: Installing your interactive
whiteboard system
Choosing a location 9
Choosing a height 10
Connecting the components of your interactive whiteboard system 11
Locking the pen tray to your interactive whiteboard 11
Installing your audio system 12
Routing the cables 12
Using SMART software 12
See the included documents for instructions on how to cable your SMART Board 800ixe-SMP, install
your product and use the mounting template.
I M P O R T A N T
Use the SMART Board 885ixe-SMP interactive whiteboard system installation guide
( smarttech.com/kb/157628 ) and the SMART Board 885ixe-SMP interactive whiteboard system
cabling diagram ( smarttech.com/kb/170258 ) to install your interactive whiteboard system.
This chapter provides additional considerations and details for installing your interactive whiteboard
system.
Choosing a location
Choose a location for your interactive whiteboard system that’s far from bright light sources, such as
windows and strong overhead lighting. Bright light sources can cause distracting shadows on your
interactive whiteboard and can reduce the contrast of the projected image.
Select a wall with a flat, regular surface and sufficient clearance to accommodate your interactive
whiteboard system. Install the projector and your interactive whiteboard on the same flat surface. For
best presentation alignment, mount your interactive whiteboard system in a location that’s central to
your audience’s viewing direction.
Chapter 2
9
