Chapter 5:

Integrating other devices

Video format compatibility

41

Native video format

41

Video format compatibility

41

HD and SD signal format compatibility

42

Video system signal compatibility

43

Connecting peripheral sources and outputs

43

This chapter provides information on integrating your SMART Board 800ixe-SMP interactive

whiteboard system with appliance with peripheral devices.

Video format compatibility

Your projector has a native video format and various video format compatibility modes. You can

change image appearances for certain formats and compatibilities.

Native video format

The following table lists the native VESA RGB video format for the projector.

Resolution

Mode

Aspect ratio Refresh rate

(Hz)

Horizontal
frequency
(kHz)

Pixel clock
(MHz)

1280 × 800

WXGA

16:10

60

48

83.5

Video format compatibility

The following tables list the projector’s compatible VESA RGB video formats by resolution, which

you can adjust by using the aspect ratio commands described in Adjusting projector settings on page

24.

Resolution

Mode

Aspect ratio

Refresh rate (Hz) “Match Input”

appearance

720 Ч 400

720Ч400_85

9:5

85.039

Letterbox

640 × 480

VGA 60

4:3

59.94

Pillarbox
