Main Frame
201
7
❖ ❖ ❖ ❖ Master Eject Unit Capacity:
• A3 drum
More than 60 masters
• A4 drum
90 masters
❖ ❖ ❖ ❖ Dimensions (W ЧЧЧЧ D ЧЧЧЧ H)
❖ ❖ ❖ ❖ Weight:
• Machine:
Less than 97kg, 213.4 lb
❖ ❖ ❖ ❖ Noise Emission *1
Sound power level
Sound pressure level *2
*1 The above measurements made in accordance with ISO 7779 are actual value.
*2 It is measured at the position of the operator.
❖ ❖ ❖ ❖ Power Consumption:
• Making a master:
Less than 0.34kW
• Printing:
Less than 0.25kW
Width Depth Height
Stored 730mm, 28.8" 700mm, 27.6" 585mm, 23"
Stored with docu-
ment feeder 730mm, 28.8" 700mm, 27.6" 695mm, 27.4"
Set up 1435mm, 56.5" 700mm, 27.6" 585mm, 23"
Set up with cabinet 1435mm, 56.5" 700mm, 27.6" 1,020mm, 40.2"
Set up with cabinet
and document feeder
(when you use A3,
11"
× 17" or larger pa-
per)
1435mm, 56.5" 700mm, 27.6" 1,130mm, 44.5"
Mainframe only
Stand-by --
During printing 120cpm
Mainframe only
Stand-by --
During printing 120cpm
