Operation
88
1
• There is no limit to the number of areas you can designate on a single com-
mand sheet.
• If designated areas on two or more command sheets overlap, the last com-
mand sheet will apply to the overlapping portion.
• If you use Outline mode for letter images with a thickness of less than 3mm,
0.12", the print image might come out as expected.
- - - -Notes
The image might differ depending on how the designated area is drawn, so re-
member the following when making the command sheet.
Designated area Area recognized Preferred designated area
Part of the designated area is
surrounded by 3 sides of the en-
tire area. Make a space of at least 2mm,
0.08", in front of the area surround-
ed by 3 sides (relative to the feed
direction).
1, 2 = 2mm, 0.08"
Double line pattern. Only the outer line is
recognized. Make a gap of at least 2mm, 0.08"
in width.
1 2
