4-14

SPS 3000 Series Programmer’s Guide

Select Static to manually assign an IP address, subnet mask, default gateway, DNS and
WINS address used by the adapter.

Figure 4-8. IP Config Property Page

Table 4-2. Config Property Page Fields

Field

Description

IP Address

The Internet is a collection of networks whose users
communicate with each other. Each communication carries the
address of the source and destination networks and the
particular machine within the network associated with the user
or host computer at each end. This address is called the IP
address (Internet Protocol address). Each node on the IP
network must be assigned a unique IP address, which is made
up of a network identifier and a host identifier. This address is
typically represented in dotted-decimal notation, with the
decimal value of each octet separated by a period, for
example, 192.168.7.27.
