Woodstock SHOP FOX W1678 - Manual (Page 45)

-43-
PARTS
REF PART # DESCRIPTION REF PART # DESCRIPTION
4 X1678004 SIDE PANEL
5 X1678004A SIDE PANEL
6 X1678006 SPROCKET 10-TEETH
7 X1678007 SPROCKET W/SHAFT
8 X1678008 TABLE LEAD SCREW 3 ⁄
4
"-16
9 X1678009 ELEVATION CHAIN
13 X1678013 DUST PORT (FLAT BASE)
14 X1678014 HOOD
15 X1678013A DUST PORT (CURVED BASE)
16 X1678016 REAR PANEL
18 X1678218 MOTOR PULLEY
19 XPK23M KEY 5 X 5 X 25MM
20 X1678020 5-HP MOTOR
201 XPB18 HEX BOLT 3 ⁄
8
"-16 X 1"
202 XPN08 HEX NUT 3 ⁄
8
"-16
203 X1678203 BRACKET
204 XPB18 HEX BOLT 3 ⁄
8
"-16 X 1"
205 XPW02 FLAT WASHER 3 ⁄
8
"
206 XPN08 HEX NUT 3 ⁄
8
"-16
208 XPSS07 SET SCREW 1 ⁄
4
"-20 X 1 ⁄
2
"
210 XPB19M HEX BOLT M8-1.25 X 24MM
211 XPW02 FLAT WASHER 3 ⁄
8
"
214 X1678214 RIGHT HOOD ARM
215 X1678215 LEFT HOOD ARM
216 XPS17M PHLP HD SCR M4-0.7 X 6MM
217 XPHTEK7 SELF TAP SCREW #8 X 3 ⁄
8
"
218 XPN04M HEX NUT M4-0.7
219 X1678219 HINGE
220 XPS38M PHLP HD SCR M4-0.7 X 10MM
221 XPLN01M LOCK NUT M4-0.7
227 XPSB07 CAP SCREW 5 ⁄
16
"-18 X 3 ⁄
4
"
228 XPN02 HEX NUT 5 ⁄
16
"-18
230 X1678230 LATCH
231 XPHTEK7 SELF TAP SCREW #8 X 3 ⁄
8
"
235 X1678235 DUST SCOOP
236 XPB02 HEX BOLT 1 ⁄
4
"-20 X 5 ⁄
8
"
237 XPN05 HEX NUT 1 ⁄
4
"-20
238 X1678238 TABLE LEAD SCREW 3 ⁄
4
"-16
239 X1678239 GEAR 25-TEETH
240 XPK06M KEY 5 X 5 X 10MM
241 XPLN06 LOCK NUT 1 ⁄
2
"-13
244 X1678244 BEARING SEAT
245 XPB51 HEX BOLT 1 ⁄
4
"-20 X 5 ⁄
8
"
246 X1678246 BEARING TA-810
248 XPS01 PHLP HD SCR #10-24 X 1 ⁄
2
"
249 X1678249 SPRING WASHER 3 ⁄
16
"
250 X1678250 BEARING 698
251 XPB05 HEX BOLT 1 ⁄
4
"-20 X 3 ⁄
4
"
259 XPW07 FLAT WASHER 5 ⁄
16
"
261 XPN02 HEX NUT 5 ⁄
16
"-18
264 XPW18 FLAT WASHER 3 ⁄
16
"
265 XPW01 FLAT WASHER 1 ⁄
2
"
269 X1678269 FRONT PANEL
271 XPHTEK7 SELF TAP SCREW #8 X 3 ⁄
8
"
272 X1678272 LOGO (SHOP FOX)
273 X1678273 LOGO SCREW #4- 3 ⁄
8
"
274 XPSW10 STRAIN RELIEF 3 ⁄
4
"
279 X1678279 LABEL (MACHINE DATA)
280 X1678280 LABEL (KEEP HANDS)
281 X1678281 LABEL (DUST MASK)
282 X1678282 LABEL (DO NOT STAND)
283 X1678283 ADHESIVE FOAM SRIP
284 X1678284 LABEL (DOWN/UP)
286 X1678286 LEFT/RIGHT COLOR-STRIPE
287 X1678287 FRONT/REAR COLOR STRIPE
289 X1678289 LABEL (UNPLUG SANDER)
290 X1678290 LABEL (SAFETY GLASSES)
291 X1678291 220V MTR CORD 5' 12-GA
292 X1678292 GROMMET 30MM
293 X1678293 FRONT BRACE
294 X1678294 REAR BRACE
295 X1678020-2 RUN CAPACITOR
296 X1678296 HANDLE
297 X1678297 FRAME
298 X1678020-1 START CAPACITOR
