-39-
PARTS
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 X1678001 SCALE
2 XPHTEK7 SELF TAP SCREW #8 X 3 ⁄
8
"
3 XPK34M KEY 5 X 5 X 20MM
10 XPN02 HEX NUT 5 ⁄
16
"-18
11 XPSB05 CAP SCREW 1 ⁄
4
"-20 X 3 ⁄
4
"
12 XPW06 FLAT WASHER 1 ⁄
4
"
17 X1678017 ADJUSTMENT PLATE
23 XPSS08 SET SCREW 5 ⁄
16
"-18 X 1 ⁄
2
"
29 X1678029 SPECIAL BOLT
32 XPN03 HEX NUT 3 ⁄
4
"-16
36 XPSB05 CAP SCREW 1 ⁄
4
"-20 X 3 ⁄
4
"
37 XPS06 PHLP HD SCR #10-24 X 3 ⁄
8
"
39 X1678039 1 ⁄
3
HP FEED BELT MOTOR
40 X1678040 POINTER
41 XPS07 PHLP HD SCR 1 ⁄
4
"-20 X 3 ⁄
8
"
42 XPW06 FLAT WASHER 1 ⁄
4
"
43 X1678043 DRIVE CHAIN
44 X1678044 SPROCKET 16-TEETH
45 X1678045 TABLE
46 XPFH12 FLAT HD SCREW 1 ⁄
4
"-20 X 1"
47 XPLN02 LOCK NUT 1 ⁄
4
"-20
49 X1678049 TABLE FRAME
50 X1678050 LEFT ROLLER-END GUARD
51 X1678051 ROLLER BRACKET
52 XPSS11 SET SCREW 1 ⁄
4
"-20 X 1 ⁄
4
"
54 X1678054 MOTOR BRACKET
55 XPB12 HEX BOLT 5 ⁄
16
"-18 X 1- 1 ⁄
4
"
56 XPW07 FLAT WASHER 5 ⁄
16
"
57 X1678057 SPROCKET 16-TEETH
59 X1678059 RIGHT ROLLER-END GUARD
61 X1678061 BUSHING SUPPORT
62 XPW06 FLAT WASHER 1 ⁄
4
"
63 XPSS05 SET SCREW 5 ⁄
16
"-18 X 1 ⁄
4
"
64 X1678064 PLATE
65 X1678065A DRIVE ROLLER
66 X1678065B IDLER ROLLER
67 XPB05 HEX BOLT 1 ⁄
4
"-20 X 3 ⁄
4
"
68 X1678068 SPROCKET 24-TEETH
69 X1678069 CONVEYOR BELT
74 X1678074 BUSHING
75 X1678075 SPROCKET SHAFT
76 XP6201 BALL BEARING 6201
77 X1678077 VS MOTOR CORD 5' 14-GA
