-41-
REF PART # DESCRIPTION REF PART # DESCRIPTION
70 X1678070 PRESSURE ROLLER
71 X1678071 SANDING DRUM
74 X1678074 BUSHING
81 X1678081 BEARING BLOCK
88 X1678088 COMPRESSION SPRING
92 X1678092 FINE SNDPPR 3" X 195"
93 X1678093 COARSE SNDPPR 3" X 195"
94 X1678094 DRUM PULLEY
98 X1678098 V-BELT B-67
101 X1678092A HOOK-AND-LOOP DRUM COVER
104 XPK10 KEY 1 ⁄
4
" X 1 ⁄
4
" X 1- 1 ⁄
4
"
105 XPSS09 SET SCREW 3 ⁄
8
"-16 X 1 ⁄
2
"
106 XPSS02M SET SCREW M6-1.0 X 6
107 XPSS08 SET SCREW 5 ⁄
16
"-18 X 1 ⁄
2
"
109 X1678109 ADJUST PLATE
110 XPLN01 LOCK NUT 3 ⁄
8
"-16
111 XPW02 FLAT WASHER 3 ⁄
8
"
112 XPLN02 LOCK NUT 1 ⁄
4
"-20
113 X1678113 LEFT FLANGE
114 X1678114 RIGHT FLANGE
115 X1678115 SPECIAL BOLT
116 XPSB01 CAP SCREW 1 ⁄
4
"-20 X 5 ⁄
8
"
117 XPSB12 CAP SCREW 5 ⁄
16
"-18 X 1- 1 ⁄
4
"
118 X1678118 AXLE
119 X1678119 BEVEL GEAR
120 X1678120 BEVEL GEAR
121 XPSS29 SET SCREW 10-24 X 1 ⁄
4
"
122 X1678122 THRUST BEARING SEAT
123 X1678123 THRUST BEARING 51101
124 XPR09M EXT RETAINING RING 20MM
125 XPSS34 SET SCREW #10-24 X 1 ⁄
2
"
126 XPN11 HEX NUT #10-24
127 X1678127 DUST COVER
128 XPHTEK6 SELF TAP SCREW #10 X 3 ⁄
8
"
129 X1678129 GEAR MOUNTING BRACKET
130 X1678130 DRIVE SHAFT BRACKET
133 X1678133 LOCK COLLAR
135 X1678135 DRIVE SHAFT
136 X1678136 MICRO-ADJUST KNOB
137 XPSS04 SET SCREW 1 ⁄
4
"-20 X 5 ⁄
16
"
138 X1678138 LOCK LEVER 5 ⁄
16
" X 18
139 XPW07 FLAT WASHER 5 ⁄
16
"
140 XPN02 HEX NUT 5 ⁄
16
"-18
141 XPW07 FLAT WASHER 5 ⁄
16
"
142 X1678142 BRACKET
143 XPB02 HEX BOLT 1 ⁄
4
" -20 X 5 ⁄
8
"
144 XPN05 HEX NUT 1 ⁄
4
"-20
145 XPB51 HEX BOLT 1 ⁄
4
"-20 X 3 ⁄
8
"
146 XPW06 FLAT WASHER 1 ⁄
4
"
148 XPR08M EXT RETAINING RING 19MM
151 X1678151 SPRING GUIDE
154 X1678154 GREASE ZERK W/CAP
- D3162 60-GRIT SNDPPR 3" X 50'
- D3163 100-GRIT SNDPPR 3" X 50'
- D3164 150-GRIT SNDPPR 3" X 50'
PARTS
