Conserver XL Series Technical Manual 7610-002-10-23
Issued: 11-28-2007 Revised: N/A
SECTION 5: PARTS SECTION
CMR ASSEMBLY OPTIONS (CONTINUED)
ITEM QTY DESCRIPTION Mfg. No.
1 1 Hood Weldment (Conserver XL2-CMR Shown) 05700-002-54-36
1 1 Hood Weldment (Conserver AXL2-CMR with Centered Control Box Not Shown) 05700-003-38-90
2* 1 Cantilever Arm Assembly 05700-002-07-70
1 Cantilever Arm Weldment 05700-002-09-13
2 Plug 05340-011-35-00
2 Spring Pin, 1/4” Dia. x 1-1/8” Long 05315-407-06-00
2 Yoke Assembly 05700-000-75-77
3 1 Tub Weldment 05700-002-54-34
4* 2 Inner Door Guide 05700-002-07-21
5 1 Front Door Assembly 05700-003-01-62
1 Front Door 05700-003-01-61
2 Door Glide, UHMW 05700-111-33-59
6 1 Hinge, Slotted 05700-002-07-39
7 2 Front Door Bracket 05700-002-07-37
8 1 Frame Weldment 05700-002-61-22
9 1 Left Rear Door Guide 05700-021-84-71
A Yoke Assembly 05700-000-75-77
10 1 Yoke 05700-000-75-78
11 1 Pin, Clevis, 5/16” x 1-3/8” 05315-700-01-00
12 2 Washer, Nylon 05311-369-03-00
13 1 Bushing 03120-100-03-00
14 1 Cotter Pin, 3/32” x 3/4” 05315-207-01-00
15 1 Nut, 3/8”-16, SS, Center Locknut 05310-256-04-00
16 1 Chemical Feed Tube Weldment 05700-002-08-14
1 Gasket, Chemical Feeding Tube 05700-011-45-36
1 Bushing, 3/4” Hole, Snap 05975-002-47-54
17 1 Control Box Assembly N/A
18 2 Spring Rod 05700-001-28-18
19 2 Spring 05340-109-02-00
20 2 Bolt, Hanger Eye 05306-956-05-00
21 2 Washer, Impeller 05311-176-02-00
22 4 Nut, Hex, 3/8”-16, SS 05310-276-01-00
23 1 Left Door Assembly 05700-002-08-84
1 Left Door Weldment 05700-002-08-60
2 Door Glide, UHMW 05700-111-33-59
1 Magnet, Reed Switch 05930-111-51-68
2 Locknut, 8-32 Hex with Nylon Insert 05310-272-02-00
24 1 Front Door Guide 05700-021-44-94
25 1 Bracket, Side Door Connecting 05700-002-07-33
Rack Rail Assembly 05700-002-08-85
26 1 Rack Rail Weldment 05700-002-07-64
27 3 Locknut, 10-24 with Nylon Insert 05310-373-01-00
28 3 Screw, 10-24 x 1/2” Long SS 05305-173-18-00
29 1 Guard, Front Track 05700-002-07-44
* Represents an item not shown.
64
