SECTION DESCRIPTION PAGE
I. GENERAL
Specifications for the Conserver XL
2
Specifications for the Conserver XL2 Series 3
Dimensions Conserver AXL (Universal Timer) 4
Dimensions Conserver AXL2 (Universal Timer) 5
Dimensions Conserver AXL2-CML (Universal Timer) 6
Dimensions Conserver AXL2-CMR (Universal Timer) 7
Dimensions Conserver XL (Starting with S/N 04D10286) 8
Dimensions Conserver XL2 9
Dimensions Conserver XL2-CML 10
Dimensions Conserver XL2-CMR 11
Conserver AXLS Option 12
Table Dimensions 13
II. INSTRUCTIONS & OPERATION INSTRUCTIONS
Installation Instructions
15
Electrical Installation Instructions 16
Chemical Dispensing Equipment 17
Operation Instructions 18
Mechanical Cam Timer Operation 20
Mechanical Timing Sequence Conserver XL 22
Universal Timer Programming Instructions 23
III. PREVENTATIVE MAINTENANCE 25
IV. TROUBLESHOOTING SECTION 27
V. PARTS SECTION
Control Box Assembly (Universal Timer) 37
Control Box Assembly (Mechanicla Timer) 39
XLS Bowl Option 41
Mechanical 8 Cam Timer 43
Chemical Feeder Pump Assembly 44
Hood Assembly (Starting with S/N 04D10286) 45
Hood Assembly, Conserver XL2 46
Cantilever Arm Assembly, Double Bracket Mount 47
Cantilever Arm Assembly, Conserver XL2 Single Bracket Mount 49
Conserver XL Wash Tub & Frame Assembly (Starting with S/N 04D10286) 50
Wash Tub Assembly (Left Front View), Conserver XL2 51
Wash Tub Assembly (Right Front View), Conserver XL2 52
Frame Weldment & Accumulator, Conserver XL2 Series 53
Incoming Plumbing Assemblies 54
1/2” Water Arrestor Assembly 54
Solenoid Valve Repair Kits, 3/4” 55
Vacuum Breaker Repair Kit, 3/4” NPT 55
Wash Motor Assembly, Conserver XL 56
Pump & Motor Assembly 57
Wash Arm /Wash Manifold Assembly 58
Drain Solenoid Assembly 59
Miscellaneous Parts 60
Conserver XL2-CML Assembly Options 61
Conserver XL2-CML Assembly Options 63
Hood Assembly, Conserver XL (Prior to S/N 04D10286) 65
Conserver XL Door & Wrap Assemblies (Prior to S/N 04D10286) 66
Frame Assembly & False Panel, Conserver XL (Prior to S/N 04D10286) 67
False Panel Installation 68
TABLE OF CONTENTS
iii
