Table 83: Gigabit Ethernet uPIM RJ-45 Connector Pinout (continued)
Function Signal Name Pin
Bidirectional pair +B BI_DB+ 3
Bidirectional pair +C BI_DC+ 4
Bidirectional pair -C BI_DC- 5
Bidirectional pair -B BI_DB- 6
Bidirectional pair +D BI_DD+ 7
Bidirectional pair -D BI_DD- 8
Gigabit Ethernet ePIM RJ-45 Connector Pinout
Table 84 on page 234 describes connector pinout information for 1-port Gigabit
Ethernet ePIM ports.
Table 84: Gigabit Ethernet ePIM RJ-45
Connector Pinouts
Signal Pin
MDI0+ 1
MDI0- 2
MDI1+ 3
MDI2+ 4
MDI2- 5
MDI1- 6
MDI3+ 7
MDI3- 8
Chassis Console Port Pinouts
The console port on a J-series Services Router chassis has an RJ-45 connector.
Table 85 on page 235 provides RJ-45 chassis console connector pinout information.
An RJ-45 cable is supplied with the router.
To connect the console port to an external management device, you need an RJ-45
to DB-9 serial port adapter, which is also supplied with the router.
234 ■ Gigabit Ethernet ePIM RJ-45 Connector Pinout
J2320, J2350, J4350, and J6350 Services Router Getting Started Guide
