Channelized PICs
•
lists the channelized IQ PICs supported by T1600 router.
•
lists the enhanced channelized IQ (IQE) PICs supported by T1600
router.
Table 2: Channelized IQ PICs Supported by the T1600 Router
First Junos OS
Release
Support
Connectors
Model Number
Ports
PIC Family and Type
8.5
Coaxial
•
Standard DS3 BNC coaxial
cable interfaces
PB-4CHDS3-QPP
4
“Channelized DS3 IQ PIC
(T1600 Router)” on page 36
8.5
•
Optical: SC/PC
PB-1CHOC3-SMIR-QPP
1
“Channelized OC3 IQ PIC
(T1600 Router)” on page 45
8.5
•
Optical: SC/PC
PB-1CHSTM1-SMIR-QPP
1
“Channelized STM1 IQ PIC
(T1600 Router)” on page 63
Table 3: Channelized Enhanced IQ (IQE) PICs Supported by the T1600 Router
First Junos OS
Release
Support
Connectors
Model Number
Ports
PIC Family and Type
9.3
Coaxial
•
Standard DS3 BNC coaxial
cable interfaces
PB-4CHDS3-E3-IQE-BNC
4
“Channelized DS3/E3
Enhanced IQ (IQE) PIC (T1600
Router)” on page 38
9.5
•
120-ohm RJ-48C
connector (female)
PB-1OCHE1-T1-IQE-RJ48
10
“Channelized E1/T1 Enhanced
IQ (IQE) PIC (T1600 Router)”
on page 42
9.3
•
Optical: LC/PC
PB-2CHOC3-STM1-IQE-SFP
2
“Channelized OC3/STM1
Enhanced IQ (IQE) PIC with
SFP (T1600 Router)” on
page 47
“Channelized OC12/STM4 Enhanced IQ (IQE) PICs with SFP (T1600 Router)” on page 52
9.3
•
Optical: LC/PC
PB-1CHOC12-STM4-IQE-SFP
1
•
Channelized OC12/STM4
Enhanced IQ (IQE) PIC with
SFP
9.4
•
Optical: LC/PC
PB-4CHOC12-STM4-IQE-SFP
4
•
Channelized OC12/STM4
Enhanced IQ (IQE) PIC with
SFP (Type 2)
