Channelized OC3/STM1 Enhanced IQ (IQE) PIC with SFP (T1600 Router)
• Junos OS Release 9.3 and later (Type 1)
For information on which FPCs support this PIC, see “T1600 PIC/FPC Compatibility” on page 18 .
Software release
• Two OC3 or STM1 ports
• SONET or SDH is configurable on a per-port granularity
• SONET channelization:
• 2 OC3 channels
• 6 DS3 channels
• 168 DS1 channels
• 1011 DS0 channels
• SDH channelization:
• 2 STM1 channels (non-concatenated)
• 6 E3 channels
• 126 E1 channels
• 6 DS3 channels (Junos OS Release 10.1 and later)
• 168 DS1 channels (Junos OS Release 10.1 and later)
• 1011 DS0 channels
• Power requirement: 0.56 A @ 48 V (27.1 W)
• Model number: PB-2CHOC3-STM1-IQE-SFP
Description
• Ports are numbered 0 and 1 from left to right Hardware features
Software features • Dynamic, arbitrary channel configuration
• Quality of service (QoS) per channel: weighted round-robin (WRR), random early detection
(RED), weighted random early detection (WRED)
• Enhanced fine-grained queuing per logical interface. See the Junos OS Class of Service
Configuration Guide for more information about class of service features.
47 Copyright © 2013, Juniper Networks, Inc.
