Specifications
Center unit (XV-THA9R)
Powered Sub-woofer (SP-PWA9)
Satellite Speakers (SP-XSA9)
Center Speaker (SP-XCA9)
Designs & specifications are subject to change without notice.
Audio section
Total Harmonic Distortion 0.02 %
AUX Input Level 290 mV/47 k
Ω
Video section
Horizontal Resolution 500 lines
Signal-to-Noise Ratio 68 dB
Output Level S-video-Y: 1.0 Vp-p/75
Ω
S-video-C: 0.286 Vp-p/75
Ω
Composite: 1.0 Vp-p/75
Ω
Tuner section
Tuning Range FM: 87.5 MHz to 108.0 MHz
AM: 522 kHz to 1,629 kHz
Usable Sensitivity FM: 17.8 dbf (2.1 µV/75
Ω
)
AM loop antenna: 630 µV/m
Dimensions (W
×
H
×
D) 360 mm
×
77 mm
×
253 mm (14-3/16 inches
×
3-1/16 inches
×
9-31/32 inches)
Mass 3.0 kg (6.6 lbs)
Power Requirements AC 230 V Ó, 50 Hz
Power Consumption 20 W (at operation)
1.9 W (in standby mode)
Amplifier section
Output Power Front/Rear/Center: 20 W
×
5, 4
Ω
, 1 kHz, 0.7 % THD
: 30 W
×
5, 4
Ω
, 1 kHz, 10 % THD
Sub-woofer : 100 W, 4
Ω
, 100 Hz, 0.7 % THD
: 140 W, 4
Ω
, 100 Hz, 10 % THD
Speaker section
Speaker 20 cm (7.9 inches), bass-reflex
Frequency Range 25 Hz to 200 Hz
Dimensions (W
×
H
×
D) 240 mm
×
435 mm
×
455 mm (9-1/2 inches
×
17-3/16 inches
×
17-15/16 inches)
Mass 16.5 kg (36.4 lbs)
Power Requirements AC 230 V Ó, 50 Hz
Power Consumption 120 W (at operation)
0 W (in standby mode)
Speakers 7 cm × 4 cm (2-15/16 inches × 1-5/8 inches) bass-reflex, Magnetically Shielded
Power Handling Capacity 30 W
Frequency Range 95 Hz to 20 kHz
Dimensions (W × H × D) 65 mm × 122 mm × 117 mm (2-9/16 inches × 4-13/16 inches × 4-5/8 inches)
Mass 360 g (0.79 lbs)
Speakers 7 cm
×
4 cm (2-3/4 inches
×
1-5/8 inches) bass-reflex, Magnetically Shielded
Power Handling Capacity 30 W
Frequency Range 95 Hz to 20 kHz
Dimensions (W × H × D) 122 mm × 65 mm × 115 mm (4-13/16 inches × 2-9/16 inches × 4-9/16 inches)
Mass 360 g (0.79 lbs)
