AT-200GE
- 61 -
0xB090
Line Selector
Line8-LVDS In
Line8
RW
4
Line Mode
LineMode
0=Input 1=Output
Line Format
LineFormat
0=Internal Logic Signal
1=TTL
2=LVDS
3=Opto-coupled
0xB0B0
Line status
R
4
See the current input and
output line
Pulse Generator
Address
Display Name
(JAI Control Tool)
GenICam name
Read /
Write
Size Value / Range of value
Description
Default
value
0xB004
Clock Pre-scaler
ClockPreScaler
RW
4
0x000
0x001
0x002
|
0xFFF
Bypass
Divide by 2
Divide by 3
|
Divide by 4096
0
0xB008
Pulse Generator Length 0
PulseGeneratorLength0
RW
4
1～1048575
Defines the length of the
counter 0
1
0xB00C
Pulse Generator Start
Point 0
PulseGeneratorStartPoint
0
RW
4
0～1048574
Defines the starting point
of the counter 0
0
0xB010
Pulse Generator Repeat
Count 0
PulseGeneratorRepeatCo
unt0
RW
4
0 - 255
Defines the repeat count of
the counter 0
0
0xB014
Pulse Generator End
Point 0
PulseGeneratorEndPoint0
RW
4
1～1048575
Defines the end point of
the counter 0
1
0xB018
Clear Mode for the Pulse
Generator 0
PulseGeneratorClear0
RW
4
0 :Free Run
1:High Level
2: Low Level
4: Rising Edge
8: Falling Edge
0
0xB01C
Pulse Generator Length 1
PulseGeneratorLength1
RW
4
1～1048575
Defines the length of the
counter 1
1
0xB020
Pulse Generator Start
Point 1
PulseGeneratorStartPoint
1
RW
4
0～1048574
Defines the starting point
of the counter 1
0
0xB024
Pulse Generator Repeat
Count 1
PulseGeneratorRepeatCo
unt1
RW
4
0 - 255
Defines the repeat count of
the counter 1
0
0xB028
Pulse Generator End
Point 1
PulseGeneratorEndPoint1
RW
4
1～1048575
Defines the end point of
the counter 1
1
0xB02C
Clear Mode for the Pulse
Generator 1
PulseGeneratorClear1
RW
4
0 :Free Run
1:High Level
2: Low Level
4: Rising Edge
8: Falling Edge
0
0xB090
Pulse Generator Selector
Pulse Generator 0
PulseGenerator0
RW
4
Pulse Generator Source
Bit 31 ～ 25
Bit24:Inverter
0:False (Active high)
1:True(Active Low)
Pulse Generator Source
127:OFF
1: LVAL IN
3:DVAL IN
5:FVAL IN
7:EEN
9:LINE4(OPT IN 1)
10:LINE5(OPT IN 2)
11:LINE8(LVDS In)
12:LINE6(TTL IN 1)
13:LINE7(TTL IN 2)
16:Pulse Gen. 0
17:Pulse Gen.1
20:User Output 0
0xB094
Pulse GeneratorSelector
Pulse Generator 1
PulseGenerator1
RW
4
