AT-200GE

- 55 -

Register Map

The table below provides detailed information for the hardware registers used for controlling
the camera and obtaining information on the status of the camera. The content of this
register map is also found in the XML file, as stipulated by the GenICam standard.

Image Format Control

Address

Display Name
(JAI Control Tool)

GenICam name

Read /
Write

Size Value / Range of value

Description

Default
value

0xA400

Width Max

WidthMax

R

4

1624

Width max

1624

0xA404

Height Max

HeightMax

R

4

1236

Height max

1236

0xA410

Pixel Format

PixelFormat

RW

4

0x02180014
0x0220001C
0x0220001D

RGB8Packed
RGB10V1Packed
RGBV10V2Packed

RGB 8

0xA500

ROI Mode

ROIMode

RW

4

1 to 5

1:ROI disable
2 to 5: Enable

1

0xA504

ROI 1 Width

Width

RW

4

8 - 1624

Width

W.Max

0xA508

ROI 1 Height

Height

RW

4

8 – 1236

Height

H.Max

0xA50C

ROI 1 Offset X

OffsetX

RW

4

0 – 1616

Horizontal offset

0

0xA510

ROI 1 Offset Y

OffsetY

RW

4

0 – 1228

Vertical offset

0

0xA514

ROI 2 Width

Width2

RW

4

8 - 1624

Width 2

W.Max

0xA518

ROI 2 Height

Height2

RW

4

8 – 1236

Height 2

H.Max

0xA51C

ROI 2 Offset X

OffsetX2

RW

4

0 – 1616

Offset X2

0

0xA520

ROI 2 Offset Y

OffsetY2

RW

4

0 – 1228

Offset Y2

0

0xA524

ROI 3 Width

Width3

RW

4

8 - 1624

Width 3

W.Max

0xA528

ROI 3 Height

Height3

RW

4

8 – 1236

Height 3

H.Max

0xA52C

ROI 3 Offset X

OffsetX3

RW

4

0 – 1616

Offset X3

0

Device Information

Address

Display Name
(JAI Control Tool)

GenICam name

Read /
Write

Size Value / Range of value

Description

Default
value

0x0048

Device Vendor Name

DeviceVendoeName

R

32

Manufacture of this device

0x0068

Device Model Name

DeviceModelName

R

32

Model Name of this device

0x0088

Device Version

DeviceVersion

R

32

Version of this device

0x00A8

Device Manufacturer
Info

DeviceManufacturerInfo

R

48

Provides extended
manufacturer information
about the device.

0x00D8

Device ID

DeviceID

R

16

Camera serial number

0x00E8

Device User ID

DeviceUserID

RW

16

User assignable string (16
Byte)

0xA714

FPGA version

DeviceFPGAVersion

R

4

0xA640

Device Reset

DeviceReset

W

4

Command=1

0xA1FC

Temperature

Temperature

R

4

0.0625° step

-55 ℃ ~ 150 ℃
