AT-200GE
- 25 -
9.2.1 Guide line for network settings
To ensure the integrity of packets transmitted from the camera, it is recommended to follow
these simple guidelines:
1. Whenever possible use a peer-to-peer network.
2. When connecting several cameras going through a network switch, make sure it is
capable of handling jumbo packets and that it has sufficient memory capacity.
3. Configure inter-packet delay to avoid congestion in network switches.
4. Disable screen saver and power save functions on computers.
5. Use high performance computers with multi-CPU, hyper-thread and 64-bit CPU, etc.
6. Only use Gigabit Ethernet equipment and components together with the camera.
7. Use at least Cat5e and preferably Cat6 Ethernet cables.
8. Whenever possible, limit the camera output to 8-bit.
☞
For more details regarding network settings, please refer to the “Getting Started Guide”
which is a separate document.
9.2.2 Video data rate (network bandwidth)
The video bit rate for the AT-200GE in Continuous mode is:
Model
Pixel Type
Frame Rate
Packet data volume
(assumes the packet size is 4036)
AT-200GE
RGB8Packed
15.4 fps
752 Mbit/s
RGB10V1Packed
RGB10V2Packed
14 fps
(Note 1)
912 Mbit/s
Note1:The frame rate of 15.4 fps exceeds 1 Gbps and the grame rate will be reduced. This
figure will depend on the system configuration used (RESEND not possible)
Note2:If Jumbo Frames (Max.16020) are not used, the packet data will be bigger by 2%.
Note3:If Jumbo frames are used, the packet size may be automatically optimized to a smaller size.
Note4:For details of setting Jumbo Frames, please refer to the “Getting Started Guide”.
9.2.3 Note for setting packet size
The packet size is set to 1476 as the factory default. Users may enter any value for the
packet size and the value will be internally adjusted to an appropriate, legal value that
complies with the GenICam standard. The packet size can be modified in the GigE Vision
Transport Layer Control section of the camera control tool.
Regarding data transfer rate, a larger packet size produces a slightly lower data transfer
rate. The AT-200GE can support a maximum of 16020 byte packets provided the NIC being
used has a Jumbo Frames function with a setting of a 16020 bytes or larger.
Caution: do not set the packet size larger than the maximum setting available in the
NIC or switch to which the camera is connected . Doing so will cause output to be
blocked.
