AT-200GE

- 49 -

9.7.8 Optical Black transfer mode
It is possible for the user to decide whether the optical black (OB) portion of the image will
be transferred or not. The optical black part can be used for black reference in the
application software. Setting register 0xA41C turns the optical black transfer ON or OFF. The
default condition is OFF.

OB Transfer Mode OFF

OB Transfer Mode ON

Normal Scan


1 1624
1



1236


1 1624 1640
1




1236

Fast Dump
(Partial Scan)


1 1624
1




1 1624 1640
1

Vertical
Binning


1 1624
1


618


1 1624 1640
1

16 e


618


Note: The menu for ON or OFF of OB transfer mode is found in the Image Format Control
section of the JAI SDK Camera Control Tool.










16 pixels
for
horizontal
are added

16 pixels
for
horizontal
are added

16 pixels
for
horizontal
are added
