AT-200GE
- 57 -
0xA020
Exposure Time (us) to
Red
ExposureTimeAbsRed
RW
4
25 to 64953( OFF)
Actual exposure time in
microseconds, µs.
The camera will round
value off to match LVAL
increments.
64953
0xA024
Exposure Time (us) to
Green
ExposureTimeAbsGreen
RW
4
25 to 64953( OFF)
Actual exposure time in
microseconds, µs.
The camera will round
value off to match LVAL
increments.
64953
0xA028
Exposure Time (us) to
Blue
ExposureTimeAbsBlue
RW
4
25 to 64953( OFF)
Actual exposure time in
microseconds, µs.
The camera will round
value off to match LVAL
increments.
64953
0xA030
Auto exposure value
AutoExposureValue
R
4
Exposure time on Auto
exposure mode
0xA040
Exposure Mode
ExposureMode
RW
4
0=Continuous trigger
1=Edge pre-select
2=Pulse-width control
4=RCT mode
9=Sequential EPS
trigger
17=Delayed readout EPS
trigger
18=Delayed readout
PWC trigger
0
0xB060
Camera Trigger 0
CameraTrigger0
Trigger Source
Bit31 ~ Bit25
Bit24:Trigger Activation
0=Rising Edge(Active
High)
1=Falling Edge(Active
Low)
Trigger Source
127=OFF
9=Line4-OpticalIn 1
10=Line5-optical In 2
12=Line6-TTL In 1
13=Line7-TTL In 2
11=Line8-LVDS In
16=Pulse Generator0
17=Pulse Generator1
20=User Output 0
(Software trigger 0)
21=User Output1
(Software trigger10)
22=User Output 2
(software trigger 2)
23=User Output 3
(Software trigger 3)
Add 0x80 makes「Active
Low」
127
0xB064
Camera Trigger 1
CameraTrigger1
0xB0A0
TimeStamp Reset Trigger
TimeStampReset
0xB0A4
Sequence Table Reset
Trigger
SequenceTableReset
0xA04C
Smearless Enable
SmearlessEnable
RW
4
0:OFF 1:ON
0xA048
LVAL Sync/Async
Accumulation
LVALSyncAccumulation
RW
4
0=Auto 1:Sync 2=Async
Video Control
Address Display Name
(JAI Control Tool)
GenICam name
Read /
Write
Size Value / Range of value
Description
Default
value
0xA050
Analog All
AnalogAll
RW
4
-89 ~ 341
Analog all
‐
89(-3dB) 341(+12dB)
1 step=0.0358dB
Value 0=0dB
0
0xA054
Analog Red
AnalogRed
RW
4
-200 ~ 200
Analog all
‐200(-6dB) 200(+6dB)
1 step=0.0358dB
Value 0=0dB
0
