AT-200GE

- 53 -

11.2. Specification table

Specifications

AT-200GE

Optical system

1/1.8 inch F4.0 prism

Scanning system

Progressive

Synchronization

Int. X-tal

Frame rate full frame

15.4 frames/second (1252 lines per frame)

Pixel clock

37.125 MHz

Line frequency

V binning

19.276 kHz (1926 clk per line)
17.381 kHz (2136 clk per line)

CCD sensors

3 x 1/1.8” IT CCD on prism. Sony ICX274AL

Sensing area

7.15 (h) x 5.44 (v) mm 1/1.8 inch diagonal

Cell size

4.4 (h) x 4.4 (v)

m

Active pixels

1624 (h) x 1236 (v)

Pixels in video output full

2/3 partial(reference value)
1/2 partial(reference value)
1/4 partial(reference value)
1/8 partial(reference value)

Variable partial

V binning

1624 (h) x 1236 (v) 15.40 fps. (1252 lines per frame)

1624 (h) x824 (v) 21.87 fps (881 lines per frame)

1624 (h) x 616 (v) 27.69 fps. (696 lines per frame)
1624 (h) x 308 (v) 45.67 fps. (422 lines per frame)

1624 (h) x 152 (v) 68.11 fps. (283 lines per frame)

Programmable start line and height, start line 1 to 1229, height 8 to 1236

1624 (h) x 618 (v) 27.68 fps. (628 lines per frame)

Sensitivity (on sensor)

(minimum)

0.8 Lux, max gain, 50% video

S/N ratio

>50 dB. (On Green)

Digital Video outputs.

GigE

®

Vision 8bit, 10 bit

Pixel format: RGB 8, RGB 10V1, RGB 10 V2

Iris video output

0.7 V p-p, 75

NUM luminance signal w/o Sync

Inputs

HIROSE 12 pin: OPT x 2

HIROSE 6 pin : TTL/75Ω x 1, LVDS x 1

Outputs

HIROSE 12 pin: OPT x 2

HIROSE 6 pin: XEEN output 4 V p-p from 75

source (TTL/75Ω)

GPIO Module

Input /Output switch
Clock Generator(one)
Pulse generator (two)

Configurable 14-in / 10-out switch

12 bit counter based on pixel clock

20-bit counter programmable for length, start point, stop point , repeat

Gain
Gain range

Manual for all 3 colors

Master -3 to +12 dB. R and B –6 to +6 dB (0.035dB step)

White balance
Tracking range

Manual/one push, continuous, preset(4000K, 4600K,5600K)

-6 to +6 dB. (4000K to 9000K)

White balance setting in factory:7800K (R and B gain settings=0)

Gamma

1.0 (OFF) , 0.6, 0.45 or LUT (Look Up Table)

Knee correction

Knee point and knee slope for R, G and B channel

Linear Matrix

Manual for R, G and B / Preset (sRGB, Adobe RGB)

Noise reduction

ON / OFF

Shading Compensation

ON /OFF (flat field and color )

Blemish Compensation

ON / OFF

Trigger modes

Edge Pre-select, Pulse Width Control, Reset continuous, Sequential EPS,

EPS/PWC delayed readout

Shutter speed

Programmable exposure

Exposure Abs

Auto shutter

0.5L(25.95µs) to 1252L(64.95ms) , increment by 1L

25µs to 64951 µs

1/15s to 1/250s

Pulse Width Control

2L to 37560 L

LVAL accumulation

SYNC/ASYNC auto detect

Smear less mode

Available for EPS and PWC

OB transfer mode

ON / OFF

Event message

Exposure start, Exposure end, Trigger IN, Video start, Video end, GPIO status

Video output connector

RJ-45 x 1

Control interface

Gigabit Ethernet (IEEE802.3, ATA GigE Vision Standard)
