Appendix B Port Descriptions and LED Status
II User’s Guide
M
ODULE
P
ORT
D
ESCRIPTIONS
The following table describes the ports on the 5000-M and 5000-M2 management
modules.
The following table describes the ports on the 5000-8G Secure Port Module (SPM).
The following table details the ports on the 5000-2G24FE SPM.
Port Description Type Speed/Protocol
Console Enables a serial connection, to establish terminal
sessions with the system. Used for launching
Command Line Interface (CLI) sessions. RJ-45 9600 Bps/
RS-232
Modem Enables a serial modem connection for
establishing dial-up sessions. RJ-45 9600 Bps/
RS-232
MGT Enables a connection for establishing out-of-band
management sessions from outside of the
network. RJ-45 10/100 Mbps/
Ethernet
HA1 Enables connection with another device in a
redundancy cluster, where one device serves as
the master (primary) device, and the other serves
as the backup (secondary) device. mini-GBIC 1 Gbps/
Gigabit Ethernet
HA2 Enables connection with another device in a
redundancy cluster, where one device serves as
the master (primary) device, and the other serves
as the backup (secondary) device. mini-GBIC 1 Gbps/
Gigabit Ethernet
Port Description Type Speed/Protocol
Network
Ports 1-8 Eight 1 Gigabit ports with an aggregate throughput
of 4 Gbps. mini-GBIC 1 Gbps/
Gigabit Ethernet
Port Description Type Speed/Protocol
Network Ports
1-2 Two high-speed network ports for general
connection to the network. mini-GBIC 1 Gbps
Gigabit Ethernet
Network Ports
3-26 24 network ports for general connection to
the network. RJ-45 10/100 Mbps/
Ethernet
