Chapter 1 Overview
10 User’s Guide
The 5000-8G2 SPM
The 5000-8G2 SPM provides eight 1-Gigabit mini-GBIC Ethernet ports using
hot-swappable transceivers. The 5000-8G2 SPM delivers up to 8 Gbps of firewall and up
to 4 Gbps of VPN capacity. This module is also capable of supporting a total of four
aggregate interfaces, with up to four ports for each aggregate interface. This SPM cannot
be mixed with the 5000-8G or 5000-2G24FE SPMs.
(For details on connecting or removing a mini-GBIC transceiver and connecting and
disconnecting a Gigabit Ethernet cable, see Chapter 4,
Servicing the Device .)
The 5000-8G2 SPM provides port Link and Activity LEDs in addition to Power and Status
LEDs.
Note: The 5000-8G2 SPM can only be managed by the 5000-M2 management module.
Power LED
Status LED
Link LED
Transmit/
Receive LED
Eight 1-Gigabit
mini-GBIC Ports
