Installing and Connecting the AC Power Supply
NetScreen-5000 Series
17
I
NSTALLING
AND
C
ONNECTING
THE
AC P
OWER
S
UPPLY
To install and connect the AC power supply to the NetScreen-5000 Series:
1.
On the NetScreen-5200, slide the power supply into one of the power
compartments in the back of the system.
On the NetScreen-5400, slide the power supply into one of the power
compartments on the front of the system.
2.
Fasten the power supply to the system by tightening the corner screws into the
eyelets on the sides of the power supply.
3.
If you want to install two power supplies in the NetScreen-5200 or three power
supplies in the NetScreen-5400, then repeat steps 1 and 2 for the remaining
power supplies.
4.
Connect the female end of a standard power cord to the male connector on the
back of each power supply.
5.
Connect each power cord to a standard 100-240-Volt power outlet.
6.
Turn the power switches on.
I
NSTALLING
AND
W
IRING
A
DC P
OWER
S
UPPLY
To install and connect the DC power supply to the NetScreen-5000 Series system:
1.
On the NetScreen-5200, slide the power supply into one of the power
compartments in the back of the system.
On the NetScreen-5400, slide the power supply into one of the power
compartments on the front of the system.
2.
Fasten the power supply to the system by tightening the corner screws into the
eyelets on the sides of the power supply.
3.
If you want to install two power supplies in the NetScreen-5200 or three power
supplies in the NetScreen-5400, then repeat steps 1 and 2 for the remaining
power supplies.
Note:
Whenever you deploy two or more power supplies to a
NetScreen-5000 Series system, connect each to a different power source.
Each power supply is intended to receive power from separate feeds.
Note:
If there are multiple power supplies in the NetScreen-5000 Series system
and any of them are off, then the Alarm LED on the management module glows
red. This alarm indicates that maximum system stability requires all installed
power supplies to be operational.
